1. Move the shipping carton to a staging area as close to the installation site as possible, but where you have enough
room to remove the system components.
2. Position the carton so that the arrows point up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory kit.
5. Pull out the packing material holding the device in place.
6. Verify that the following components are in the box:
•
The chassis with six fan modules and two power supplies installed
•
4-post rack mount kit—2 side mounting blades and 2 side mounting rails
NOTE: If you are installing the PTX10001-36MR on a two-post rack, you must order the 2-post rack mount
kit separately.
•
Sixteen flathead screws for the mounting brackets (Phillips, M4 x 6 mm)
•
For AC/HVDC installations, two power cords with plugs that are appropriate for your geographical location.
NOTE: Power cords are not provided for DC installations.
•
For DC installations, four DC power cable lugs
•
RJ-45 cable and RJ-45 to DB-9 serial port adapter
•
RJ-45 Y-splitter cable
•
End User License Agreement
•
Roadmap card
7. Save the shipping carton and packing materials in case you need to move or ship the chassis later.
Mount the PTX10001-36MR in a Rack
You can mount a PTX10001-36MR:
•
On four posts of a 19-in. rack or a 19-in. cabinet by using the mounting brackets provided with the device.
•
On two posts of a 19-in. rack or a 19-in. cabinet. A two-post rack mount kit must be ordered separately.
4
