CENTER OF GRAVITY
WEIGHT: 1.99 lbs [0.91 kg] MAX.
0.03in [0.8mm]
0.75in
19.1mm
2.40in
61mm
3.15in
80mm
J4
146.1mm MAX
5.75in MAX
1.875in MAX
47.63mm MAX
NCAGE CODE
L00N3
FINISH:
MATERIAL:
N/A
N/A
PART NO.
PREPARED TAT
JA94-N01A
CHECKED
APPROVED
SHEET
TO JUPITER AVIONICS CORP.
1/1
JUPITER AVIONICS TEMPLATE SOLIDWORKS PORTRAIT SIZEA REVB .DRWDOT
TITLE
0.5 DEG
Dual Audio Controller - NVG
JA94-N01A Mechanical Installation Rev A.SLDDRW
DOC. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES:
1 DEC PLACE: 0.1
2 DEC PLACE: 0.01
3 DEC PLACE: 0.005
ANGLES:
CONFIDENTIAL & PROPRIETARY
DRAWING NOT TO SCALE
5.48in MAX
139.2mm MAX
5.00in MAX
127.0mm MAX
0.30in MAX
7.6mm MAX
1.55in MAX
39.4mm MAX
J1
J3
J2
J5
