Jura ENA 9 One Touch Technical Information

Elektroapparate AG
Technical information
Technical Support
Language E
ENA 9 One Touch
Author: Patrik Studer Checked: Approved: Docu.-name: Technische_Information_ENA_9_E.doc
L:\Geräte\ENA\ENA_9\Schulungsunterlagen\E\Technische_I
nformation_ENA_9_E.doc
Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F:
15.09.2010 19.10.2010 24.11.2010
Page 10/11
24 Prepare appliance for resale:
Procedure:
All products will be reset to factory settings and the fluid system is empty due to protection against frost.
The appliance asks the customer for the desired language and afterwards it will fill the system with water.
Initial position:
The appliance is fully working and if necessary, an exit diagnosis has been made with the animation system.
The ENA 9 cannot be reset to factory settings, this has to be done manually.
1. Switch on appliance until the following message appears on the display READY
2. Empty the system completely (frost protection) according to the manual
Turn selector switch to the position WATER
Remove and empty the water tank
Hot water will flow until the system is empty (CLOSE TAP)
Close selector switch to the position COFFEE (FILL WATER TANK)
Press the key ON/OFF to switch off the appliance
3. Turn selector switch to the position WATER
4. Switch on again the appliance
5. Press the keys ROTARY SWITCH & MAINTENANCE simultaneously, until the message OK
appears on the display
6. Switch off the appliance
7. Turn selector switch back to the position COFFEE
25 Error messages:
§ If there is a malfunction, an error message as described below is shown on the display and
5 seconds after, the appliance switches off:
Display Message Designation
ERROR 1 COFFEE: Temperature sensor notify “value below tolerance”
ERROR 2 COFFEE: Temperature sensor notify “value above tolerance”
ERROR 5 Heating up not possible
ERROR 8 “Positioning” / “Initialisation” of brewing unit not possible
ERROR 10 Heating was too hot (mains interferences received)
TOO HOT
Maintenance programs can not be carried out, as there had been used a
steam-product before

Jura ENA 9 One Touch Specifications

General

Product type	Espresso machine
Capacity in cups	10 cups
Coffee input type	Coffee beans, Ground coffee
Coffee maker type	Fully-auto
Milk tank capacity	0.4 L
Appliance placement	Countertop
Water tank capacity	1.1 L
Coffee beans capacity	125 g
Adjustable coffee strength	Yes
Maximum operating pressure	15 bar
Number of temperature settings	2
Color name	Metallic
Cord length	1.1 m
Product color	Black, Silver
Housing material	-
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	445 mm
Width	238 mm
Height	360 mm
Weight	9400 g
