Spare parts LC 300 D
Pos Code Description Q.ty Pos Code Description Q.ty
1 1401200700 OIL DRIPPER 2 49 4022300001 OIL FILTER 1
2 1407200900 WATER PUMP SX (LC D SX) 1 50 4023100047 BEARING 6309 C3 1
1407200800 WATER PUMP DX (LC D DX) 1 51 4023110098 BEARING NU 309 ECJ/C3 1
3 1521506500
1521506400
ROTOR LC300 D
ROTOR LC300 D USA
1
52 4023250501 RUBER BALL D80 1
4 154201TWB0 BELT PROTECTION LC D SX 1
53 4024251000
4024251500
OIL PUMP CW ROTATION (LC D DX)
OIL PUMP CCW ROTATION (LC D SX)
1
154201TVB0 BELT PROTECTION LC D DX 1 54 4025350019 BELTSPZ 925 1
5 1601606400 VANE LC300 4 55 4026101301 SCREW M6X10 2
6 1605500000 HANDLE 1 56 4026102806 SCREW M8X20 7
7 1608100000 DISTRIBUTOR 1 57 4026102807 SCREW M8X25 16
8 1608501700 CONVEYOR 1 58 4026102819 SCREW M8X90 2
9 1610051700 FLANGE 1 59 4026102908 SCREW M10X30 18
10 1610508200 FLANGE 1 60 4026103030 SCREW M12x16 4
11 1610510800 FLANGE 1 61 4026120301 SCREW M6X12 4
12 1610512900 OIL PUMP FLANGE 1 62 4026121305 SCREW M6X16 2
13 1610513500 FLANGE 2 63 4026121405 SCREW M8X20 3
14 161201X4B0 PUMP SUPPORT 1 64 4026121710 SCREW M12X35 2
15 1622002600 SHAFT M10 1 65 4026135414 SCREW M8X45 1
16 1623100000 CONVEYOR FLANGE 1 66 4026135504 SCREW M10X10 1
17 1624027500 SPACER 1 67 4026171211 SCREW M12X80 2
18 1624037700 SPACER 2 68 4026305508 NUT M12 SELFLOCKING 2
19 1624042800 SPACER 2 69 4026308005 NUT M8 2
20 1624202300 4 WAYS SPACER 1 70 4026308006 NUT M10 2
21 1627505300 MANIFOLD 1 71 4026350503 WASHER GROWER M6 Q 6
22 1642100200 REAR PROTECTION 1 72 4026350505 WASHER GROWER M8 Q 6
23 165351TXB0 DRIVEN PULLEY 1 73 4026350508 WASHER GROWER M12 Q 2
24 16630D5SB0 LUBRICATION LINE 1 74 4026350706 WASHER GROWER M8 P 21
25
16630D5PB0
16630D5IB0
LUBRICATION LINE
LUBRICATION LINE USA
1
75 4026350708 WASHER GROWER M10 P 4
26 166301SZB0 LUBRICATION LINE 1 76 4026351504 TOOTHED WASHER M6 2
27 166301T0B0 LUBRICATION LINE 1 77 4026351506 TOOTHED WASHER M10 16
28 16630D5TB0 LUBRICATION LINE 1 78 4026357005 WASHER M8 2
29
16630D5XB0
16630D5WB0
LUBRICATION LINE
LUBRICATION LINE USA
1
79 4026357006 WASHER M10 4
30 16630D61B0 LUBRICATION LINE 1 80 4026357007 WASHER M12 2
31 1673001000 OIL FILTER PLUG 1 81 4026359001 WASHER 40X33.5X1.5 AL 6
32 1680609700 OIL PUMP GASKET 1 82 4026359006 WASHER 13.5X18X1.5 AL 4
33 1680611600 MANIFOLD GASKET 1 83 4026501008 TAB 12X8X70 1
34
1680611400 +
1680611500
MANIFOLD GASKET 1
84 4026510032 SEEGER E45 2
35 1680707300 FLANGE GASKET 2 85 4026702000 FITTING 6
36 1680700200 FLANGE GASKET 1 87 4026706000 FITTING 4
37 1680709700 GASKET 1 88 4026706003 FITTING 2
38 1680709800 HOUSING GASKET 2 89 4026706101 FITTING 2
39 16120CJ5B0 OIL DRIPPER FLANGE 1 90 4026904003 PLUG 1” 6
40 1685002800 WASHER 30X8.5X4 1 92 4026904300 VENT PLUG ¼” 2
41 1685100000 WASHER 14X20X1.5 AL 2 93 4026904503 PLUG M20X1.5 1
42 1685100300 WASHER D 20 2 94 4026905002 PLUG ¼” 2
43 16875BHDB0 HOUSING LC300 1 95 4026910103 PLUG 1
44 1687600000 OIL TANK 1 96 4026910601 PLUG 1/8 2
45 1691000000 SPRING 1 97
16630D5MB0
16630D5IB0
LUBRICATION LINE
LUBRICATION LINE USA
1
46
47
4022200030
4022200044
Y-SEAL 41X27X10
Y-SEAL 65X45X8
1
1
98
16630D60B0
16630D60B0
LUBRICATION LINE
LUBRICATION LINE USA
1
48 4022200416 Y-SEAL 60X75X8 4 99
16630D5WB0
16630D5WB0
LUBRICATION LINE
LUBRICATION LINE USA
1
