jurop LC 420 Original Instruction

……………………………………………………………….…………………………
……………………………………………………………….…………………………
26 / 32
Spare parts LC 300-420 M540 - M1000 - HDR
Pos Code Description Q.ty Pos Code Description Q.ty
1 GEARBOX 540 – 1000 RPM 44 4026351506 TOOTHED WASHER M10 15
1 4025350019 BELT SPZ 925 1 45 4026351505 TOOTHED WASHER M8 11
2 1407200900 WATER PUMP SX 1 46 4026356002 FLAT WASHER 8X24 3
(LC M SX - LC HDR DX) 47 4026401806 PIN10X36 2
1407200800 WATER PUMP DX 48 4026501003 TAB 12X8X40 1
(LC M DX - LC HDR SX) 49 162403N3B0 SPACER 1
3
1521506800
1521505800
ROTOR LC300 M
ROTOR LC420 M
1
50 161201X4B0 WATER PUMP SUPPORT 1
4 154201TUB0 PROTECTION (LC M SX – HDR DX)
1 51 4025426003 BUSHING 1
154201TSB0 PROTECTION (LC M DX – HDR SX)
52 4025426209 PULLEY 150X1 SPZ 1
5 1610512900 OIL PUMP SUPPORT 1 53 4026102819 SCREW M8X90 1
6 1610513500 FLANGE 1 54 4026102908 SCREW M10X30 1
7 1610513600 GEARBOX M 1 55 4026308006 NUT M10 2
8 1613501400 OIL PUMP FLANGE 1 56 4026350708 WASHER GROWER M10 P 4
9 1622002600 SHAFT M10 1 57 4026350706 WASHER GROWER M8 P 21
10 1624037500 SPACER 2 58 4026357005 WASHER M8 1
11 1624037700 SPACER 1 59 4026357006 WASHER M10 6
12 1640501200 GEARBOX FLANGE 1
13 1642100200 REAR PROTECTION 1
14 4029602806 DRIVE SHAFT PROTECTION 1
15
1651005500
1651010700
PINION Z28 (540 RPM)
PINION Z42 (1000 RPM)
1
2 HYDRAULIC DRIVE
16
1651010500
1651010600
GEAR Z70 (540 RPM)
GEAR Z56 (1000 RPM)
1
H1 1470102300 JOINT 1
17 1680609700 OIL PUMP GASKET 1 H2 1521506700 ROTOR LC300 HDR 1
18 1680614100 GEARBOX GASKET 1 1521506000 ROTOR LC420 HDR
19 1680709800 HOUSING GASKET 2 H3 1610513500 FLANGE 2
20 1680710000 GASKET 1 H4 1612501000 BRACKET HDR 1
21 1681006500 COMP. RING FLANGE 1 H5 1610021600 FLANGE HDR 1
22 1684000000 PLUG 3/8” 3 H6 1624037700 SPACER 1
23 1685100100 WASHER 10X16X1.5 CU 2 H7 1680707300 GASKET 1
24 1685100200 WASHER 17X22X1.5 AL 3 H8 1680709800 GASKET 1
25 4022200008 Y-SEAL 90X45X8 1 H9 4022200044 Y-SEAL 65X45X8 1
26 4022200416 Y-SEAL 60X75X8 4 H10 4022200416 Y-SEAL 60X75X8 2
27 4022200040 Y-SEAL 72X40X10 1 H11 4024107009 MOTOR LC300 1
28 4023100040 BEARING 6308 1 4024107001 MOTOR LC420
29 4023100047 BEARING 6309 C3 1 H12 4026101613 SCREW M12X40 2
30 4023110098 BEARING NU 309 ECJ/C3 1 H13 4026136006 SCREW M8X14 1
31 4023100020 BEARING 6207 1 H14 4026102908 SCREW M10X30 8
32 4026102804 SCREW M8X16 3 H15 4026136003 SCREW M8X8 1
33 4026102809 SCREW M8X35 8 H16 4023110098 BEARING NU309 ECJ/C3 2
34 4026102908 SCREW M10X30 16 H17 4026171211 SCREW M12X80 4
35 4024251000 OIL PUMP DX 1 H18 4026121405 SCREW M8X20 3
(LC M SX - LC HDR DX) H19 4026171304 SCREW M14X40 4
4024251500 OIL PUMP SX H20 4026308008 NUT M14 4
(LC M DX - LC HDR SX) H21 4026305508 NUT M12 SELFLOCKING 4
36 4026121305 SCREW M6X16 2 H22 4026350609 WASHER GROWER M12 P 4
37 4026121710 SCREW M12X35 6 H23 4026350610 WASHER GROWER M14 P 4
38 4026121813 SCREW M10X50 2 H24 4026351506 WASHER M10 8
39 4026155503 SCREW M5X12 4 H25 4026351505 WASHER M8 3
40 4026300025 COMPENSATION RING 1 H26 4026359001 WASHER 40X33.5X1.5 AL 1
41 4026306115 BOLT M36X3 SELFLOCKING 1 H27 4026510032 SEEGER E45 1
42 4026350503 WASHER GROWER M6 Q 6 H28 4026904003 PLUG 1" 1
43 4026350508 WASHER GROWER M12 Q 6 H29 4026501004 TAB 12X8X45 1
