PUMP LUBRICATION HOUSING GEARBOX
LS:
Tank level
CS:
Tank filling
point
OL:
Oilers
CL : Vanes wear
checking
LM:
Oil level
SM:
Outlet plug
CM:
Inlet plug
Model LC300 D LC300 M LC300 HDR LC420 D LC420 M LC420 HDR
Weight (kg)
195 200 205 210 215 220
The LC pumps are designed to convey filtered air into plants for vacuum production or for the suction
of powders or liquid wastes. Do not sack toxic substances and inflammable or explosive gasses since
the internal components of the pump may reach high temperatures.
Liquids or solids infiltrations can seriously damage the pump.
MAX. SPEED – OPERATING SPEED
P
2
(ABS bar)
T
2
(°C)
T
2
- T
1
(°C)
LC … M 540 LC … M 1000 LC … DIR LC … HDR
Max Max Max
540 - 460 1000 - 850 1300 - 1100 1300 - 1100
2.0 150°C 130°C
P
1
: absolute pressure during suction T
1
: temperature during suction
P
2
: absolute pressure during delivery T
2
: temperature during delivery
LEGEND OF LUBRICATION AND VANES WEAR CHECK-POINTS
WEIGHT
