jurop LC 420 Original Instruction

……………………………………………………………….…………………………
……………………………………………………………….…………………………
31 / 32
Accessories LC420
Pos Code Description Q.ty Pos Code Description Q.ty
3 143028GZB0 PNEUMATIC OPERATED 4-WAY KIT 6 THREADED MANIFOLD
P1 160858KBB0 CONVEYOR 1 F2 1627504900 THREADED MANIFOLD 1
P2 161258H0B0 ACTUATOR SUPPORT 1 F3 4026351505 TOOTHED WASHER M8 12
P3 1640580QB0 ACTUATOR COVER 1 F4 4026102807 SCREW M8X25 12
P4 167007ZAB0 CONVEYOR NUT 1 F5 4026135504 SCREW M10X10 1
P5 1680707800 FALNGE GASKET 1
P6 168409PQB0 RING NUT 1 7 1852103400 FIXED SUCTION CONVEYOR Ø80 KIT
P7 168529TFB0 SPACER 1 C1 1627101300 CONVEYOR Ø80 1
P8 1691000200 SPRING 1 C2 4022200310 OR 6362 1
P9 4022100100 GREASING NIPPLE M6X1 1 C3 4026102807 SCREW M8X25 4
P10 4022200005 Y-SEAL 37X27X7 1 C4 4026350706 WASHER GROWER M8 4
P11 4022200330 OR 3375 1
P12 4022200331 OR 2137 1 8 1852103500 FIXED SUCTION CONVEYOR Ø100 KIT
P13 4026102804 SCREW M8X16 4 C1 1627101200 CONVEYOR Ø100 1
P14 4026102807 SCREW M8X25 4 C2 4022200310 OR 6362 1
P15 4026121405 SCREW M8X20 4 C3 4026102807 SCREW M8X25 4
P16 4026350505 WASHER GROWER M8 4 C4 4026350706 WASHER GROWER M8 4
P17 4026351505 TOOTHED WASHER M8 8
P18 4027100405 PNEUMATIC ACTUATOR 1 9 1852103900 TURNING CONVAYOR Ø80 KIT
P19 4027421206 FITTING R15 6XG1/8 2 C5 1610101100 CONVEYOR FLANGE 1
C6 1627102700 CONVEYOR Ø80 1
4 143029KRB0 HYDRAULIC OPERATED 4-WAY KIT C7 4022200310 OR 6362 1
R1 143027T6B0 HYDRAULIC ACTUATOR 1 C8 4026102808 SCREW M8X30 4
R2 15020A10B0 ACTUATOR LEVER 1 C9 4026350706 WASHER GROWER M8 4
R3 151307TJB0 ACTUATOR SUPPORT 1
R4 1624043400 SPACER 1 10 1852104000 TURNING CONVAYOR Ø100 KIT
R5 1624202300 SPACER 1 C5 1610101100 CONVEYOR FLANGE 1
R6 164206XYB0 PROTECTION 1 C6 1627102400 CONVEYOR Ø100 1
R7 1685002800 WASHER 30X8.5X4 1 C7 4022200310 OR 6362 1
R8 168509U0B0 WASHER 1 C8 4026102808 SCREW M8X30 4
R9 4026121408 SCREW M8X35 4 C9 4026350706 WASHER GROWER M8 4
R10 4026121405 SCREW M8X20 2
R11 4026135414 SCREW M8X45 1 11 1852104100 KIT FOR SAFETY VALVE
R12 4026155705 SCREW M8X16 1 S1 1627102500 CONVEYOR 1
R13 4026308005 NUT M8 4 S2 4022200310 OR 6362 1
R14 4026350505 WASHER GROWER M8 6 S3 4026102807 SCREW M8X25 4
R15 4026510012 SEEGER E14 7435 1 S4 4026102810 SCREW M8X40 4
R16 4022100100 GREASING NIPPLE M6X1 1 S5 4026308005 NUT M8 4
R17 1623100500 CONVEYOR FLANGE 1 S6 4026350706 WASHER GROWER M8 8
R18 1680707800 FLANGE GASKET 1
R19 1608502500 CONVEYOR 1 12 185212L4B0 SUCTION FILTER KIT
R20 1691000000 SPRING 1
R21 1624027500 SPRING SPACER 1
5 FLANGED MANIFOLD
F1 1627504800 FLANGED MANIFOLD 1
F3 4026351505 TOOTHED WASHER M8 12
F4 4026102807 SCREW M8X25 12 189207X0B0 GASKETS KIT LC420 M 1
F5 4026135504 SCREW M10X10 1 189207X2B0 GASKETS KIT LC420 D 1
