85
LCD Flat TelevisionType
Reception Format
Power Source
Power Consumption
Model
NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable
AC 120V, 60 Hz
Screen Size
Speakers
Audio Output 10W + 10W
Antenna Terminal
(VHF/UHF,
ATSC/DIGITAL
CABLE IN)
75 ohms (F-type connector) x 2
External Input Jacks
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance
Component Input
Jack
Y: 1Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
S-Video Input Jacks
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Digital–In
HDMI jack x 2
Note: The Digital–In terminal is not compatible with picture signals of a
personal computer
Refer to "unpacking your TV", page 7
Dimensions (inch/cm)
W X H X D
Weight (lbs / kg)
Accessories
Optical Output
Digital Audio
Digital Out (optical) x 1
Reception Range
VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper
and Ultra bands (191 channel frequency synthesizer system) at Analog
• Reception of channel A-5 ("95" of the TV set's on-screen cable channel
numbers) is not recommended for your TV set.
VHF 2 to 13, UHF 14 to 69 at ATSC,
CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable
PC Input Jack
Analog RGB D-SUB (15 pin) x 1, RS-232C (9 pin) x 1*
• PC signal is available. Refer to page 23 for details on the signals which
can be input.
255W
LT-40FH97
LT-40FN97
6.6cm oblique x 2, 6.6cm woofer x 2
40 inch / 101.5 cm
measured diagonally,
16:9 ratio
39 3/8 x 29 x 12 3/4
(with stand)
100 x 73.4 x 32.5
(with stand)
39 3/8 x 26 1/2 x 4 5/8
(without stand)
100 x 67.1 x 11.8
(without stand)
68.2 / 31 (with stand)
55 / 25 (without stand)
Monitor/Recording
Output
Video: 1Vp-p, 75ohms
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Audio: 250mVrms (-10dBs)
Fs-18dB Low Impedance
i.LINK In/Out Jack
TS IN/OUT (4-pin, S400) x 2
IEEE1394 compliant DTCP digital copy protection compatible
LT-46FH97
LT-46FN97
286W
46 inch / 116.9 cm
measured diagonally,
16:9 ratio
4cm x 16cm twin oblique x 2
44 3/8 x 30 1/2 x 13 1/2
(with stand)
112.6 x 77.5 x 34.1
(with stand)
44 3/8 x 28 1/2 x 4 3/4
(without stand)
112.6 x 72.2 x 12
(without stand)
83.6 / 38 (with stand)
69.3 / 31.5 (without stand)
Specifications subject to change without notice.
• The open source software is embedded in this product. For more information, please go to:
http://software.jvc.com/opensource/lnx/DP/04_AtscCC/download.html
* RS-232C is only for LT-40FH97 and LT-46FH97. See page 8.
Specifications
