JVC AV-14F3 User Manual

No. 52026
A
V-14F3/AV-1435
A
V-1435EE/AV-1435TEE
A
V-14FMT3/AV-1438
A
V-14FMG3/AV-14FMG3B
14
REPLACEMENT OF IC301 (IF V/C DECODER)
" For the I C301(I F V/C DECODER) of this mode l, a ll data are written in the micro-computer. So, wri te the data in the micro-
computer in accordance with the following procedures before starting adjustment.
PROCEDURES
(1) Tur n t he POWE R O FF.
(2) Replace t he IC30 1 with a n ew o ne .
(3) While pressing ME NU bu tto n a nd VO L+ bu tton ON the FRONT CABINET sim ulta ne ous ly, t urn th e POW ER ON. W he n the POW ER is
turned ON, the data is writ ten in t he micro-co mp uter immediately.
LOCATIONS OF FRONT PANEL BUTTONS AND LAM PS
MENU buttons
CHANNEL ･ / ･ buttons
(ME NU ･ / ･ butt ons)
VOLUME
－
/
＋
buttons
(MENU
－
/
＋
bu ttons)
AI ECO sensor
REMOTE CONTROL sensor
ON TIMER lamp
POWER lamp
MAIN POW ER button
MENU buttons
CHANNEL －/＋buttons
(ME NU －/＋buttons)
VOLUME
－
/
＋
buttons
(MENU
－
/
＋
bu ttons)
AI ECO sensor
REMOTE CONTROL sensor
ON TIMER lamp
POWER lamp
MAIN POW ER button
1
2
3
4
5
6
7
8
