BASIC OPERATION OF SERVICE MENU
"
The adjustment using SERVICE MENU
The f ollowing adjus tment it ems u se t he SE RV ICE MENU in th e ser ies of the adju stment . The ad ju stment s ar e made on the bas is of the
initial se tting valu es. Th e ad justment valu es which ad ju st t he screen to th e o ptimum co ndit ion c an b e diffe rent from the in itia l sett ing va lues.
With th e S ERVICE ME NU, var ious s ett in gs c an be made , and the y ar e br oa dly classifie d in th e f ollo win g ite ms of s ettin gs.
1.I F ･･･････ ･････････････ ･･･ Adjustment of the IF circuits.
2.V /C ･･･････ ･････････････ ･･ Ad justmen t of the VIDEO /CHRO MA circuit.
3.DEF ･･･････ ･････････････ ･ Adjustment of th e DEFLECTION circ uit.
4.V SM PRES ET ･･･････ ･････ Ad ju stmen t of th e init ial sett ing va lue s of VSM co nd it ion as STA NDA RD, SOFT a nd BRIGHT.
(VSM : Video Status Memory)
5.PRESET
･･･････ ･･････････
Adjustment of the RF circ uit [Do not adjust].
6.SETUP TOUR OFF ････････ It s hou ld b e able to select mode (LANGUAG E and AUTO CH PRESE T).
[Shou ld be OFF].
"
Key operation of the SERVICE MENU
[Enter to SERVICE MENU]
Press the DISPLAY key and the PICTURE MODE key of the REMOTE CONTROL
UNI T simult an eou sly. Th en ent er th e S ERVICE ME NU mod e as sh own in Fig.1 .
[Exit from SERVICE MENU]
When com plete th e ad just ment wor k, pr ess th e DI SPLAY key to return t o the
SERVICE MENU.
An d then press th e DI SPLAY ke y ag ain, return to th e n or m al screen .
[ Se lec t from SE R VICE M E NU]
In SERVI CE M ENU, pr ess t he n umber (1 ～6) ke y of th e r em o te c ont rol un it , to se lect
an y of th e ad justmen t ite ms.
The colo urs which se lected ite m ch aract ers a re ch ang ed .
SE RVICE MENU
To Next Page
