No. 51686
V-27D201
V-32D201
15
[THEATER]
1) Select
THEATER
item, then press the LEFT or RIGHT
key in main SERVICE MENU, the each screens will be
displayed as shown in figure page later.
2) Then the settings or verifications can be performed.
[LOW LIGHT / HIGH LIGHT]
1) Select any of LOW LIGHT or HIGH LIGHT items, then press the LEFT or RIGHT key in main SERVICE MENU, the each screens will
be displayed as shown in figure page later.
2) Then the settings or verifications can be performed.
3) The details of adjustments are described in the WHITE BALANCE page in ADJUSTMENT.
[RF AFC]
1) Select RF AFC item, then press the LEFT or RIGHT key in main SERVICE MENU, the each screens will be displayed as shown in
figure page later.
2) Then the settings or verifications can be performed.
[VCO(CW)]
1) Select the
VCO(CW)
item, press the LEFT or RIGHT key in main SERVICE MENU, the screen will be displayed as shown in figure
page later.
2) Then UP or DOWN key is pressed, the
VCO(CW)
mode screen is displayed, and the
VCO(CW)
setting can be performed.
3) The details of adjustments are described in the WHITE BALANCE page in ADJUSTMENT.
[Adjustment steps]
1) Select the setting item, and enter to its mode.
2) Adjust its values. When the key is released, the setting values will be stored (memorized).
3) Returns to the previous screen.
TINT
COLOR
BRIGHT
DETAIL
R CUT.
G CUT.
B CUT.
R DRIVE
B DRIVE
GMM L
GMM G
D AX RY
D RT BY
GY R SW
THEATER MODE
THEATER MODE
SETTING VALUE
The letters of the selected
items are displayed in
yellow.
To Next Page
