JVC AV-27F476 - Page 18

1-18 (No.YA243)
No.
Setting
item
Variable
range
Initial setting value
AV-32F476/Z
RF
EXTERNAL
(
S / COMPOSITE )
EXTERNAL
(COMPONENT)
STANDARD THEATER STANDARD STANDARD
4 : 3 16 : 9 4 : 3 4 : 3 4 : 3
S01 BRIGHT 0 - 127 64 --- --- --- ---
S02 PICTURE 0 - 127 50 --- --- --- ---
S03 COLOR 0 - 127 45 --- --- --- 45
S04 TINT 0 - 127 56 --- --- --- 70
S05 DETAIL 0 - 63 35 --- --- 40 40
S06 BRIGHT+- -32 - +32 --- ±0 +3 -2 -3
S07 PICT+- -32 - +32 --- -8 -7 +2 ±0
S08 COLOR+- -32 - +32 --- ±0 -3 -1 ---
S09 TINT+- -32 - +32 --- ±0 -3 +14 ---
S10 DETAIL+- -32 - +32 --- --- ±0 --- ---
No.
Setting
item
Variable
range
Initial setting value
AV-27F476/R
AV-27F476/S
RF / EXTERNAL (S / COMPOSITE) EXTERNAL (COMPONENT)
STANDARD THEATER STANDARD THEATER
LOW HIGH LOW HIGH LOW HIGH LOW HIGH
S11 R CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S12 G CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S13 B CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S14 R DRIVE 0 - 127 64 --- --- --- --- --- --- ---
S15 B DRIVE 0 - 127 64 --- --- --- --- --- --- ---
S16 R CUT +- -128 - +127 --- ±0 ±0 ±0 -5 --- --- ---
S17 G CUT +- -128 - +127 --- ±0 ±0 ±0 ±0 --- --- ---
S18 B CUT +- -128 - +127 --- ±0 ±0 ±0 -6 --- --- ---
S19 R DRV +- -128 - +127 --- +5 +13 +7 ±0 --- --- ---
S20 B DRV +- -128 - +127 --- +6 -25 -9 ±0 --- --- ---
S21NTSC MAT0 - 333112211
S22 BLACK ST 0 - 3 2 --- 2 --- --- --- --- ---
S23 DC REST 0 - 1 1 --- 1 --- --- --- --- ---
S24 DCRSW 0 - 1 1 --- 1 --- --- --- --- ---
No.
Setting
item
Variable
range
Initial setting value
AV-32F476/Y
AV-32F476/Z
RF / EXTERNAL (S / COMPOSITE) EXTERNAL (COMPONENT)
STANDARD THEATER STANDARD THEATER
LOW HIGH LOW HIGH LOW HIGH LOW HIGH
S11 R CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S12 G CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S13 B CUT OFF 0 - 255 30 --- --- --- --- --- --- ---
S14 R DRIVE 0 - 127 64 --- --- --- --- --- --- ---
S15 B DRIVE 0 - 127 64 --- --- --- --- --- --- ---
