1-20 (No.YA243)
4.7.2 [2. DEF (D)]
No.
Setting
item
Variable
range
Initial setting value
AV-27F476/R
AV-27F476/S
AV-32F476/Y AV-32F476/Z
RF
EXTERNAL
RF
EXTERNAL
RF
EXTERNAL
4 : 3 16 : 9 4 : 3 4 : 3 16 : 9 4 : 3 4 : 3 16 : 9 4 : 3
D01V FREQ0 - 3 003003003
D02AFC GAIN0 - 3 002002002
D03 H POSI 0 - 31 21 --- 21 19 --- 19 19 --- 19
D04 H POSI+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D05 V PHASE 0 - 7 0 --- 0 0 --- 0 0 --- 0
D06 V PH+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D07 V SIZE 0 - 127 105 --- 105 58 --- 58 45 --- 45
D08 V SIZE+- -128 - +127 --- -30 --- --- -30 --- --- -30 ---
D09 V CENTER 0 - 63 32 --- 32 32 --- 32 32 --- 32
D10 V CENT+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D11 V S CORR 0 - 15 7 --- 7 9 --- 9 8 --- 8
D12 V S CO+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D13 V LIN 0 - 15 10 --- 10 10 --- 10 8 --- 8
D14 V LIN+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D15 H SIZE 0 - 63 38 --- 38 49 --- 49 28 --- 28
D16 H SIZE+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D17WVMT TOP0 - 3 010010010
D18WVMT BTM0 - 3 010010010
D19 EWCR TOP 0 - 31 14 --- 14 14 --- 14 11 --- 11
D20 EWCR T+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D21 EWCR BTM 0 - 31 13 --- 13 16 --- 16 11 --- 11
D22 EWCR B+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D23 EW PARA 0 - 63 42 --- 42 35 --- 35 31 --- 31
D24 EW PARA+- -128 - +127 --- -15 --- --- -16 --- --- -16 ---
D25 V EHT 0 - 7 0 --- 0 0 --- 0 0 --- 0
D26 V EHT+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D27 H EHT 0 - 7 0 --- 0 0 --- 0 0 --- 0
D28 H EHT+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D29 TRAPEZ 0 - 63 30 --- 30 34 --- 34 36 --- 36
D30 TRAPEZ+- -128 - +127 --- 0 --- --- 0 --- --- 0 ---
D31V AGC 0 - 1 000000000
D32BLANK SW0 - 1 000000000
D33VRMP BI0 - 1 000000000
To Next Page
