JVC AX-V8000 - Parts List

No. MB177 3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~07)
Packing materials and accessories parts list (Block No.M3)
[ AX-V8000 ]
3- 2
3- 6
3-32
Area suffix
UP ---------------------------- Korea
