General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10535-024A FRONT PANEL
2 EXO150010H09S11 FELT SPACER
3 LV10536-026A FRONT BASE
4 LV30225-0D5A SPACER
5 LV43855-001A JVC MARK
6 E60912-003 SPEED NUT
7 LV43263-002A K2 MARK
8 E408131-001 REMOTE LENS
9 LV42395-001A INDICATOR
10 LV32831-002A GUIDE(L)
11 LV32832-002A GUIDE(R)
12 QYSDSF2608M TAP SCREW M2.6 x 8mm(x4)
13 LV32812-001A PUSH BUTTON
14 LV32813-002A PUSH BUTTON
15 LV32826-003A INDICATOR
16 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
17 LV32815-009A PUSH BUTTON
18 LV32816-002A PUSH BUTTON
19 LV32817-009A PUSH BUTTON
20 LV32818-002A PUSH BUTTON
21 LV32814-001A PUSH BUTTON
22 FSYS4004-004 WASHER
23 QYSDSF2608Z SCREW 2.6mm x 8mm(x9)
24 LV42684-001A BARRIER
25 E310243-002 PLASTIC RIVET
26 E65923-003 TAPPING SCREW
27 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
28 LV32811-009A LENS
29 LV42095-003A FL SCREEN
30 LV42405-003A VOL RING
31 LV42726-002A VOL.SPACER
32 LV21375-003A SIDE FITTING(L)
33 LV21376-003A SIDE FITTING(R)
34 QYSBSF3008Z SCREW 3mm x 8mm(x6)
35 LV21061-002A DOOR
36 LV21062-003A DOOR BASE
37 LV21065-003A PUSH BUTTON (x2)
38 WJT0073-001A E-CARD WIRE
39 LV30225-074A SPECER
40 QYSDSF2004Z TAP SCREW M2 x 4mm(x6)
41 QYSSSG2004Z TAP SCREW M2 x 4mm(x8)
42 QYSSSG2004Z TAP SCREW M2 x 4mm(x2)
43 QYSDSF2606Z SCREW 2.6mm x 6mm(x3)
44 LV32835-002A G.P. BKT(L)ASSY
45 LV32836-002A G.P.BKT(R)ASSY
46 QYSDSF2606Z SCREW 2.6mm x 6mm(x4)
47 LV42478-001A WORM GEAR
48 LV32837-002A MOTOR BASE
49 LV41536-201A PULLEY
50 LV41598-001A BELT
51 LV32838-001A WORM WHEEL
52 QAR0100-001 DC MOTOR
53 WJM0233-001A E-SI C WIRE C-F
54 QYSPSP3004Z SCREW M3 x 4mm(x2)
55 LV32830-001A MAIN SHAFT
56 LV42400-001A MAIN GEAR
57 LV42729-002A SPRING
58 QYREE3000X E RING M3
59 LV32833-002A H.BKT(L) ASSY
60 LV32834-002A H.BKT(R) ASSY
61 LV42396-002A ARM (x2)
62 QYREE3000X E RING M3(x2)
63 QYREE6000X E RING M6(x4)
64 LV42397-001A S.STOPPER(L)
65 QYSDSG2606Z TAP SCREW M2.6 x 6mm
66 LV42398-001A S.STOPPER(R)
67 LV32839-001A WHEEL STOPPER
68 QYSBSF3008Z SCREW 3mm x 8mm(x3)
69 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
70 QYSDSF2606M TAP SCREW M2.6 x 6mm(x4)
71 LV42783-001A EARTH PLATE
72 LV43235-005A SHEET
73 LV10537-006A BOTTOM PLATE
74 E70115-002 CAUTION LABEL
75 E47227-042 FOOT ASSY (x2)
76 QYSBST3010Z TAPPING SCREW 3mm x 10mm(x2)
77 LV43562-001A STEEL FOOT (x3)
78 LV40247-001A FOOT (x3)
79 QYSPST3016M TAP SCREW M3 x 16mm(x3)
80 LV10541-003A SIDE BKT(L)
81 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
82 E73967-006 SPACER (x4)
83 LV10542-004A TRANS BASE
84 QYSDSG3008E TAP SCREW M3 x 8mm(x10)
85 LV10543-003A CENTER BKT(L)
86 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x5)
87 LV10544-002A CENTER BKT(R)
88 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x5)
89 LV21066-002A SIDE BKT(R)
90 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
91 E73967-006 SPACER (x2)
92 LV10539-003A FRONT BKT
93 LV41603-001A LEAF SPRING
94 QYSBSG3008E TAPPING SCREW 3mm x 8mm
95 LV30225-071A SPACER (x4)
96 E73967-006 SPACER
97 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x9)
98 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x5)
99 LV30225-0C8A SPACER
100 E310243-002 PLASTIC RIVET (x3)
101 LV43600-001A H.P.JACK BKT
102 QYSBSGG3006Z TAP SCREW M3 x 6mm
103 VKZ4150-001 SPECIAL NUT
104 QYSDSG3008E TAP SCREW M3 x 8mm(x3)
105 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
106 LV32828-006A HEAT SINK (x2)
 107 2SC3858/PG/-F1 TRANSISTOR
Q714 Q764 Q814 Q1614
Q1664 Q1714 Q1764(x7)
 108 2SA1494/PG/-F1 TRANSISTOR
Q715 Q765 Q815 Q1615
Q1665 Q1715 Q1765(x7)
109 E73525-003SS SCREW (x28)
110 QYSBSGG3010E TAP SCREW M3 x 10mm(x7)
111 QYSBSGG3010E TAP SCREW M3 x 10mm(x4)
112 QYSBSGG3010E TAP SCREW M3 x 10mm(x2)
113 LV30225-0D3A SPACER
114 LV21067-002A H.SINK BKT (x2)
115 LV30225-071A SPACER
116 LV30225-074A SPECER (x3)
117 QYSBSGG3010E TAP SCREW M3 x 10mm(x8)
118 QYSBSG3010E TAPPING SCREW 3mm x 10mm
119 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
120 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
121 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x7)
122 E310244-003 FASTENER (x4)
123 LV21068-003A SHIELD COVER
124 LV30225-0N9A SPACER
125 LV30225-0D4A SPACER (x2)
126 LV30226-034A SPACER (x2)
127 E310243-002 PLASTIC RIVET (x2)
128 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
129 LV30225-0P3A SPACER
130 E310243-002 PLASTIC RIVET
131 LV30225-0C7A SPACER
132 E310244-003 FASTENER
133 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x4)
134 LV30225-074A SPECER
135 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x6)
 136 QQT0378-002 POWER TRANSF T 41
137 QYSDSTL4008E TAP SCREW M4 x 8mm(x2)
 138 QQT0379-002 POWER TRANSF T 42
139 LV43364-001A BARRIER (x2)
140 QYSDSTL4008E TAP SCREW M4 x 8mm(x2)
 141 QQT0380-002 POWER TRANSF T 1
142 QYSDSTL4008E TAP SCREW M4 x 8mm(x4)
143 QYSBSG3008E TAPPING SCREW 3mm x 8mm
144 QYSDSG3008E TAP SCREW M3 x 8mm
145 LV10728-016A REAR PANEL
146 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x8)
147 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
148 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
 Symbol No. Part No. Part Name Description Local
