JVC CA-NXF30 - Specifications; Main Unit (CA-NXF30); Speaker (SP-NXF30 F); Subwoofer (SP-NXF30 W)

68
Reference
Tuner
FM frequency: 87.50 MHz – 108.00 MHz
Terminal (front of the main unit)
• Microphone input terminal x 2
3.0 mV/12 k
Ω
• USB digital input terminal x 1
• Audio output headphone terminal x 1
Impedance: 16 Ω – 1 kΩ
Terminal (rear of the main unit)
• Audio output speaker terminals x 1
Left/Right speakers:
Output power: 220 W (55 W x 4) at 3 Ω
(1 kHz/10% THD)
Impedance: 3 Ω – 16 Ω
Subwoofer:
Output power: 180 W at 6 Ω
(100 Hz/10% THD)
Impedance: 6 Ω – 16 Ω
• Optical digital input terminal x 1
–23dBm to –15dBm
• Optical digital output terminal x 1
–23dBm to –15dBm
• Component video output terminals x 1
Y: 1.0 Vp-p, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
• Composite video output terminal x 1
1.0 Vp-p, 75 Ω terminated
• Audio input terminals x 1
500 mV/47 kΩ
• HDMI monitor output terminal x 1
• FM antenna terminal x 1
USB
Compatible with USB 2.0 Full-Speed
Compatible device: USB mass storage class
device
Compatible file system:
FAT16, FAT32
Output power: DC 5 V 500 mA
HDMI
Output power: DC 5 V 55 mA
General
Power source (Thailand): AC 220 V , 50 Hz
Power source (other countries/areas):
AC 110 – 127 V/220 – 240 V ,
50/60 Hz
Power consumption (in operation):
100 W
Power consumption (on standby):
1W or less
Dimensions (W x H x D) [including projecting parts]:
312 mm x 95 mm x 312.3 mm
Mass: 3.5 kg
Type: 1-way bass reflex type
Magnetically shielded type
Speaker driver:
Front ch: 5.5 cm cone
Surround ch: 5.5 cm cone
Power handling capacity:
Front ch: 55 W
Surround ch: 55 W
Impedance: 3 Ω
Frequency range: 80 Hz – 20 kHz
Sound pressure level:
77 dB/W•m
Dimensions (W x H x D) [including projection parts]:
88 mm x 203 mm x 127 mm
Mass (1 speaker): 1.2 kg
Type: Bass reflex type
Speaker driver: 16 cm cone
Power handling capacity:
180 W
Impedance: 6 Ω
Frequency range: 30 Hz – 200 Hz
Sound pressure level: 76 dB/W•m
Dimensions (W x H x D):
300 mm x 301 mm x 303 mm
Mass: 8.2 kg
Remote control x 1
Batteries x 2
FM antenna x 1
Composite video cable x 1
AC plug adaptor* x 1
Core filter x 1
NOTE
* The AC plug adaptor is not supplied for
Thailand, Middle Eastern countries and South
Africa.
Designs and specifications are subject to change
without notice.
Main unit (CA-NXF30)
Speaker (SP-NXF30F)
Subwoofer (SP-NXF30W)
Supplied accessories
Specifications
