CH-X1500
1-9
2.4.6 Remove the top plate (See fig.17,18)
(1) Remove the nine screws J attaching the top plate.
(2) Disconnect the section d attached to the rear of the unit,
then lift the top plate slightly.
(3) Move the top plate toward the rear of the unit to remove
the upper rod from the top plate.
Fig.17
Fig.18
J
J
J
Rod
Top plate
d
J
Top plate
