2 (No.PA062<Rev.001>)
*1 D-ILA is the abbreviation for Direct Drive Image Light Amplifier.
*2 D-ILA devices are manufactured using extremely high-precision technology with a pixel effectiveness of 99.99%.
Only 0.01% or less of the pixels are either missing or would remain permanently lit.
*3 During 3D playback, the display resolution is 4096 x 2160 pixels.
*4 HDCP is the abbreviation for High-bandwidth Digital Content Protection system. The image of the HDMI input terminal may not be
displayed in some cases due to changes in the HDCP specifications.
*5 Exclusively for firmware update.
*6 The power consumption of this product during networked standby when all wired network ports are connected is 1.5 W.
*7 “During standby” refers to Eco Mode standby (Refer to instruction manual P61).
• Design and specifications are subject to change without prior notice.
• Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid compre-
hension. Images may differ from the actual product.
Product Name D-ILA Projector
Display Panel/Size D-ILA device *1, 2
0.69” 4K D-ILA (4096 x 2160 pixels) x 3
Projection Lens 2.0 x power zoom lens (1.4:1 to 2.8:1) motorized zoom and focus
Light-source Lamp 265 W ultra-high pressure mercury lamp [product no.: PK-L2618U]
Average lifespan: 4500 hours (“Low” mode)
Screen Size Approx. 60” to 280” (Aspect ratio of 16:9)
Brightness 2200 lm (N11BC, NX9BE, NX9BK, RS3000E, RS3000K)
1900 lm (N7BE, N8BC, NX7BK, RS2000E, RS2000K)
1800 lm (N5BC, N5BE, N5WE, N6BC, NX5BK, RS1000E, RS1000K)
Projection Distance Refer to instruction manual P79
Input Compatibility Signal Refer to instruction manual P83
Display Resolution 8192 x 4320 pixels *3 (N11BC, NX9BE, NX9BK, RS3000E, RS3000K)
4096 x 2160 pixels (Except N11BC, NX9BE, NX9BK, RS3000E, RS3000K)
Input Terminal HDMI Input Dual HDMI 19-pin x 2 (HDCP 2.2-compatible) *4
Output Terminal Trigger Terminal Single
Ø 3.5 mm DC Power Jack ( )
DC OUT 12 V 0.1 A
3D synchro Dedicated terminal for 3D Synchro Emitter (single mini-DIN 3-pin)
Control Terminal RS-232C Terminal Single D-sub 9-pin (male) (external control)
LAN Terminal Single RJ-45 plug 10BASE-T/100BASE-TX
Service Terminal SERVICE Single (USB Type A) *5
Power Requirements AC 100 V to 240 V, 50 Hz/60 Hz
Power Consumption 400 W (during normal standby: 1.5 W *6, during Eco Mode standby: 0.3 W *7)
Operation Environment Temperature: 5C to 35C
humidity: 20% to 80%
storage temperature: -10C to 60C
Installation Height Below 5,000 ft (1,524 m)
Dimensions (Width x Height x Depth) 500 mm x 234 mm x 518 mm (including feet) (N11BC, NX9BE, NX9BK, RS3000E,
RS3000K)
500 mm x 234 mm x 495 mm (including feet) (Except N11BC, NX9BE, NX9BK, RS3000E,
RS3000K)
Mass
21.8 kg (N11BC, NX9BE, NX9BK, RS3000E, RS3000K)
19.8 kg (Except N11BC, NX9BE, NX9BK, RS3000E, RS3000K)
