JVC DLA-X7

An array of convenient features
for the DLA-X7 and DLA-X3
User-replaceableLamp
PK-L2210U
3D Glasses
PK-AG1-B
3D Synchro Emitter
PK-EM1
Lens cover closed (power off) Lens cover open (power on)
Unique automatic lens cover
A unique automatic lens cover opens and closes upon power on/off to
protect against dust or damage, so users are assured of easy, trouble-
free operation via the remote controller, even if the projector is installed
on the ceiling.
Complies with the latest HDMI standard: Ver.1.4a
TwoHDMIVer.1.4astandardinputs,whichcomplywith3D,1080p/24
inputandDeepColor,areavailablethatarecapableofupto12bit
signalinputpercolor(approx.68.7billioncolors).Thetwoterminals
are separated far apart to allow
fortwowideHDMIcablestobe
inserted simultaneously.
DLA-X3DLA-X7
A wide range of input and output terminals
InadditiontoHDMIterminalscompatiblewithBlu-rayandDVD
sources, these projectors also feature several other terminals including
remote terminals for remote operation via connection of an extended IR
sensor, a trigger terminal for an anamorphic lens, and the X7 features a
LAN terminal for projector control.
Flexible installation guaranteed
Setting up the projector in a location ideal for projection is made easy
thankstothe±80%verticaland±34%horizontalpoweredlens-shift
function with remote control. These projectors also feature a high-
performance2xzoomlenswithmotorizedfocusthatcanprojectimages
uponalarge100-inchscreenatdistancesofbetween3.1and6.2
meters. With the high-performance motor, the once tedious tasks of
setting zoom ratios and focus adjustments are now simple and effortless.
■ Optional Equipment
±80% vertical and ±34% horizontal electric lens shift function
34% 0% 34%
80%
50%
0%
50%
80%
80%
50%
0%
50%
80%
Horizontal shift range
Vertical shift range
The vertical and horizontal lens shift function cannot be set to the maximum values simultaneously.
