19
SPECIFICATIONS
General
Format : VHS NTSC standard
Power source : DC 11 V (Using AC
Adapter)
DC 6 V (Using battery
pack)
Power consumption
Viewfinder on : 3.5 W
LCD monitor on : 4.3 W
Signal system : NTSC-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
Conforms to VHS standard
Cassette : cassette
Tape speed
SP : 33.35 mm/sec. (1-5/16 ips)
EP : 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP : 40 minutes
EP : 120 minutes
(with TC-40 cassette)
Operating
temperature : 0°C to 40°C (32°F to 104°F)
Operating humidity
: 35% to 80%
Storage temperature
: –20°C to 50°C (-4°F to 122°F)
Weight : Approx. 770 g (1.7 Ibs.)
Dimensions : 81 mm x 125 mm x 216 mm
(W x H x D) (3-1/4" x 4-15/16" x 8-9/16")
(with the LCD monitor closed
and with the viewfinder fully
tilted downward)
Pickup : 1/6" format CCD
Lens : F1.8, f = 2.2 mm to 44 mm,
20:1 power zoom lens with
auto iris and macro control
Filter diameter : ø 30.5 mm
Viewfinder : Electronic viewfinder with
0.16" black/white LCD
White balance
adjustment : Auto/Manual adjustment
LCD monitor : 2.50" diagonally measured,
LCD panel/TFT active matrix
system
Speaker : Monaural
Connectors
Video : 1 V (p-p), 75 Ω unbalanced,
analog output (via Video
output connector)
Audio : 300 mV (rms), 1 kΩ, analog
output (via Audio output
connector)
Power requirement
:
USA and Canada : AC120V - 60V ~
Other Countries : AC110V - 240V ~
50/60Hz
Output : DC 11 V , 1 A
SPECIFICATIONS
Camcorder
AC Adapter
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
GR-AXM17-EN.fm Page 19 Monday, December 20, 2004 5:20 PM
