MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
4-47
62 1.4 1.4
63 1.7 1.6
64 1.5 1.4
IC1602
1 0.4 0.4
200
3 2.2 2.2
4 3.2 3.2
5 3.2 3.2
Q1601
E 1.7 1.7
C 11.1 11.1
B 5.8 5.8
<VTR ASP>
MODE
REC PLAY
PIN NO.
IC2001
1 1.5 3.2
2 1.6 0
3 1.6 0
4 1.5 3.2
5 1.6 3.2
6 1.5 0
700
8 1.5 0
9 1.6 3.2
10 1.5 0
11 1.6 3.2
12 1.5 0
13 1.6 3.2
14 3.1 3.2
IC3501
1 2.2 2.2
2 2.2 2.5
3 2.2 2.2
4 2.2 2.1
5 2.2 2.5
6 2.2 2.2
7 4.7 4.7
8 2.2 2.1
9 2.2 2.5
10 2.2 2.1
11 2.1 2.1
12 2.2 2.5
13 2.2 2.1
14 0 0
15 3.2 0
16 2.8 1.4
17 4.0 5.2
18 0 0
19 2.8 0
20 2.8 0
21 1.1 2.1
22 0 2.1
23 2.1 2.1
24 4.7 4.7
25 2.8 2.4
26 0 2.9
27 2.5 2.5
28 2.9 2.9
29 0 0
30 1.5 1.5
31 3.2 3.2
32 0.7 0
33 3.2 3.2
34 1.8 1.8
35 1.9 0
36 0 0
37 2.6 2.3
38 3.0 3.0
39 4.7 4.7
40 2.4 2.1
41 2.2 2.1
42 2.9 2.9
43 2.8 2.5
44 2.7 2.4
45 2.4 2.5
46 2.5 2.5
47 0 0
48 2.5 2.5
49 2.5 2.5
50 0 0
51 2.4 2.4
52 2.5 2.4
53 2.5 2.5
54 4.8 4.8
55 2.4 2.5
56 0 1.4
Q2001
E 3.1 3.2
C 1.5 3.2
B 3.2 0
Q2007
1(E) -10.4 0
2(B) -16.2 0.7
3(C) 0 0
4(E) -10.4 0
5(B) -16.2 0.7
6(C) 0 0
Q2008
1(E) 3.1 1.8
2(B) 3.2 1.2
3(C) 3.2 1.2
4(E) 3.1 1.8
5(B) 3.2 1.2
6(C) -16.4 0.8
Q2021
E00
C 0.6 0
B00
Q2022
E00
C00
B00
Q2023
E00
C00
B00
Q2071
E 4.5 4.5
C 4.7 4.8
B 4.7 4.8
Q3501
1(E) 2.2 2.2
2(B) 2.4 2.2
3(C) 2.2 2.2
4(E) 2.2 2.2
5(B) 2.4 2.5
6(C) 2.2 2.2
Q3502
1(E) 2.2 2.1
2(B) 0 2.2
3(C) 2.2 2.1
4(E) 2.2 2.1
5(B) 2.3 2.2
6(C) 2.2 2.1
Q3505
E00
C 2.8 0
B 0 2.7
Q3901
1(E) 4.6 4.7
2(B) 0 4.9
3(C) 3.9 4.9
4(E) 0 0
5(B) 3.9 4.9
6(C) 0 0
<SPEAKER>
MODE
REC PLAY
PIN NO.
IC2401
1 2.9 2.9
2 1.2 1.2
3 1.2 1.2
4 0 1.3
5 1.3 1.3
6 3.2 3.2
700
8 1.3 1.3
Q2401
E00
C 2.9 2.9
B00
<DSP>
MODE
REC PLAY
PIN NO.
IC4001
1 3.2 3.2
2 0 1.2
300
4 1.6 1.6
5 3.2 3.2
6 3.2 3.2
7 1.4 1.4
8 1.4 1.4
9 1.4 1.4
10 3.2 3.2
11 1.4 1.5
12 1.4 1.6
13 1.4 1.5
14 1.4 1.6
15 0 0
16 1.4 1.5
17 1.4 1.5
18 1.5 1.5
19 1.8 1.8
20 1.4 1.5
21 1.4 1.5
22 1.4 1.5
23 1.4 1.5
24 1.4 1.5
25 1.4 1.6
26 0 0
27 1.8 1.8
28 0 0
29 0 0
30 1.6 1.6
31 0 0.6
32 3.0 3.0
33 1.8 1.8
34 3.1 3.1
35 0 0
36 3.1 3.1
37 0 0
38 2.5 0
39 1.2 1.6
40 1.2 1.6
41 3.2 3.2
42 1.2 1.6
43 1.2 1.6
44 1.9 1.6
45 1.5 1.6
46 1.6 1.6
47 0.6 1.6
48 0 0
49 1.1 1.4
50 1.2 1.4
51 1.2 1.5
52 1.6 1.5
53 1.5 1.5
54 1.6 1.6
55 0 0
56 0 0
57 0 0
58 3.2 3.2
59 1.5 1.5
60 1.5 1.5
61 1.4 1.7
62 1.3 1.5
63 1.5 1.7
64 1.7 1.5
65 1.7 1.8
66 0.9 0.9
67 1.4 1.7
68 1.4 1.7
69 0 0
70 1.8 1.8
71 1.4 1.7
72 1.6 1.6
73 1.2 1.4
74 1.2 1.3
75 1.2 1.5
76 1.8 1.8
77 1.2 1.2
78 1.3 1.5
79 1.5 1.5
80 1.5 1.5
81 0.7 0.6
82 0 0
83 1.8 1.8
84 1.1 1.5
85 1.1 1.5
86 1.2 1.6
87 1.6 1.5
88 1.5 1.4
89 0 0
90 0 0
91 0 0
92 3.0 3.0
93 0 0
94 3.2 3.2
95 2.7 2.7
96 2.8 2.7
97 2.8 2.7
98 3.2 3.2
99 0 0
100 0 1.5
101 0.6 1.7
102 1.6 1.6
103 1.0 1.5
104 0 0
105 1.9 1.5
106 1.1 1.5
107 1.1 1.5
108 1.2 1.5
109 1.2 1.5
110 1.2 1.5
111 3.2 3.2
112 1.4 1.6
113 2.9 0
114 3.1 0
115 0 0
116 0 0
117 0 0
118 1.5 1.5
119 0 0
120 0 0
121 1.5 1.6
122 1.5 1.5
123 1.8 1.8
124 3.2 3.2
125 3.2 3.2
126 0.7 0
127 0 0
128 1.8 1.8
129 1.6 1.6
130 1.5 1.5
131 1.5 1.5
132 1.5 1.5
133 1.8 1.8
134 1.5 1.5
135 3.0 3.0
136 0 0
137 1.6 1.5
