10
1
• MENU Wheel [–, +] ..................................... pg. 18
• BRIGHT Wheel [–, +] .................................. pg. 11
• TRACKING Wheel [–, +] ............................. pg. 14
2
Snapshot Button [SNAPSHOT] ..................... pg. 12
3
• Power Zoom Lever [T/W] ............................ pg. 13
• Speaker Volume Control [VOL.] .................. pg. 11
4
• Picture Stabilizer Button
[P.STABILIZER] ........................................... pg. 12
• Time Base Corrector Button [TBC].............. pg. 14
5
S-Video Output Connectors [S] ..................... pg. 15
6
Audio Output Connector [A] .......................... pg. 15
7
Video Output Connector [V] .......................... pg. 15
8
Battery Release Switch
[BATTERY RELEASE] .................................... pg. 6
9
DC IN Connector ............................................. pg. 6
0
Digital Connector [DIGITAL]
!
Recording Start/Stop Button ......................... pg. 11
@
Power Switch [ , OFF, , ] .............. pg. 11
#
Video Light Switch
[LIGHT OFF/AUTO/ON] ................................ pg. 13
$
Stop Button [STOP] ....................................... pg. 11
%
• Retake Rewind Button [RETAKE R] ............ pg. 13
• Quick Review Button [ R] ...................... pg. 13
• Rewind Button [R] ....................................... pg. 11
^
Play/Pause Button ......................................... pg. 11
&
• Retake Forward Button [RETAKE F] ........... pg. 13
• Fast-Forward Button [F] .............................. pg. 11
*
CHARGE Lamp ............................................... pg. 6
(
POWER/REFRESH Lamp .............................. pg. 6
)
• Fade/Wipe Button [FADE/WIPE] ................. pg. 22
• Counter Reset/Memory Button
[COUNTER R/M] ......................................... pg. 14
q
Program AE Button [P.AE] ............................. pg. 23
w
Digital Effect Button [DIGIFECT] ................... pg. 23
e
NIGHT-ALIVE Button .................................... pg. 22
r
REFRESH Button ............................................ pg. 6
t
EJECT Switch ................................................. pg. 8
y
Shoulder Strap Eyelets ................................... pg. 8
u
Battery Pack Mount ......................................... pg. 6
i
Close Button .................................................... pg. 8
o
Diopter Adjustment Control ............................. pg. 8
p
• Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor ....................................... pg. 9, 17
Q
Grip Strap ........................................................ pg. 8
W
Tripod Mounting Socket .................................. pg. 8
E
Infrared Beam Transmitting Window ......... pg. 9, 17
R
ZOOM (T/W) Buttons .............................. pg. 13, 24
T
PLAY Button .................................................. pg. 11
Y
REW Button (Functions the same as
%
)
U
STOP Button (Functions the same as
$
)
I
INSERT Button .............................................. pg. 24
O
• REC TIME Button ........................................ pg. 24
• ANIM. Button ............................................... pg. 24
P
START/STOP Button (Functions the same as
0
)
a
FF Button (Functions the same as
&
)
s
PAUSE Button ............................................... pg. 11
d
A.DUB Button ................................................ pg. 24
f
• INT.TIME Button .......................................... pg. 24
• SELF TIMER Button (non-functional)
1
Tape Remaining Time ................................... pg. 21
2
Recording Mode Indicator ............................. pg. 20
3
• Digital Effect Indicator ................................. pg. 23
• Program AE Indicator .................................. pg. 23
• Night-Alive Indicator .................................... pg. 22
• Fade/Wipe-Standby Indicator ...................... pg. 22
4
Recording Format Indicator (S/S-ET) ............ pg. 20
5
Tape Length Indicator .................................... pg. 21
6
Zoom Indicator Bar ........................................ pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
7
Recording Indicator ....................................... pg. 11
8
Digital Effect Indicator ................................... pg. 23
9
• Program AE Indicator .................................. pg. 23
• Night-Alive Indicator .................................... pg. 22
0
Fade/Wipe-Standby Indicator ........................ pg. 22
!
Picture Stabilizer Indicator ............................ pg. 12
@
Interval Time/Recording Time Indicator ........... pg. 21
#
Bright Level Indicator .................................... pg. 11
$
Instant Title Display ....................................... pg. 19
%
Date/Time Display ......................................... pg. 19
^
Focus Indicator .............................................. pg. 18
&
Exposure Control Level Counter ................... pg. 18
*
White Balance Mode Indicator ...................... pg. 19
(
S-VHS/S-VHS ET Recording
Indicator ........................................................ pg. 20
)
Record-Standby Mode Indicator ................... pg. 11
q
• : Cassette Indicator................................. pg. 8
• w: Insert Editing Indicator ........................... pg. 24
w
TBC Indicator ................................................ pg. 14
e
Playback Special Effect Indicator .................. pg. 14
r
Recording Format Indicator (S/S-ET) ............ pg. 20
t
Tape Counter ........................................... pg. 14, 24
y
Recording Mode Indicator (SP/EP) ............... pg. 20
u
Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
e
4
: Audio Dubbing
i
Tracking Indicator .......................................... pg. 14
o
Tape Counter ................................................. pg. 24
p
• BRIGHT: Bright Level Indicator ................... pg. 11
• VOLUME: Speaker Volume Indicator ........... pg. 11
