5-5
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
135H LY32060-003A STICKER(C),H,J
LY32060-005A STICKER(C),A,B,C,D,E,F,G
135J LY30029-0B4A SPACER(A),B,C,D,E,F,G,H,J
! 135K YQ44341-6 CAUTION LABEL,B,C,D,E,F,G,H,J
136 QYSLSF2060D SCREW,X3
139 QYSPSTU1725M SCREW
140 LY20832-001B FRAME ASSY,B,C,D,E,F,G,H,J
LY20832-002B FRAME ASSY,A
140A YQ31843 BASE
140B QYSLSF2060D SCREW,X2
140C LY30029-0A4A SPACER(A)
140D LY41082-001A CUSHION(OP),X2
140E YQ43810-1-1 CONTACT(LIGHT),X2,B,C,D,E,F,G,H,J
140F WJM0259-001A E-SI C WIRE C-F,FRAME-MAIN CN6,B,C,D,E,F,G,H,J
141 LY32327-001A SHIELD CASE(MAIN)
142 QYSPSPU1720Z SCREW
143 QYSLSF2060D SCREW
144 QYSLSF2060D SCREW
145 WJT0072-001A E-CARD WIRE,OP-MAIN CN15
146 QAL0389-001 FPC,MAIN CN22-CCD CN5301
147 LY20613-001B ZOOM UNIT
148 QYSLSF2060D SCREW,X4
149 LY41173-001A SPECIAL SCREW,X2
150 LY30018-050A SPECIAL SCREW,X2
151 QYSLSP2030D SCREW
155 LY31808-001C CASSETTE HOUSING FINAL ASSY
156 LY42722-003A SCREW,X4
157 LY30176-001A CASSETTE COVER INSIDE
158 LY31956-001A BRACKET(CASSETTE COVER)
159 LY31790-001A FRONT FRAME ASSY
159A YQ44144-1-1 TAPE GUIDE
160 SPSH1725M SCREW,X2
161 LY32326-001A BRACKET(MECHA)
162 LY42722-003A SCREW,X2
163 QYSLSF1750D SCREW
164 LY31807-001A SIDE BRACKET L
165 LY42722-003A SCREW
– OPTICAL BLOCK SECTION –
251 LY30948-003A OP BLOCK ASSY
251A PTY30948-002 FOCUS MOTOR
251B PTY30948-301 ZOOM MOTOR
251C PTY30151-016 TAPPING SCREW,X9
251D PTY30948-006 IRIS MOTOR UNIT
252 LY41757-001A OPTICAL LPF
253 LY31441-001A SPACER RUBBER
254 LY20346-001A CCD SPACER
255 LYH30374-002A CCD BASE ASSY
256 QYSPSGU2080Z SCREW,X2
257 LY30018-072A SPECIAL SCREW
******************************
FINAL ASSEMBLY <M2>
101 LY20694-010A CASSETTE COVER(M)ASSY,A,B,C,G
LY20694-011A CASSETTE COVER(M)ASSY,F,H
LY20694-012A CASSETTE COVER(M)ASSY,D,E
LY20815-001B CASSETTE COVER(M)ASSY,J
101A LY40075-004A LABEL/CAUTION
101B LY42883-001A MARK
101C LY40559-001A SHIELD SHEET
101D LY40076-001A SPACER,X2
102 QYSLSP2030D SCREW,X2
103 LY10257-050A UPPER CASE(M),G
LY10257-051A UPPER CASE(M),B
LY10257-052A UPPER CASE(M),H
LY10257-062A UPPER CASE(M),A
LY10257-063A UPPER CASE(M),D,E
LY10257-069A UPPER CASE(M),C
LY10257-070A UPPER CASE(M),J
LY10257-072A UPPER CASE(M),F
104 QYSLSP2030D SCREW,X2
105 QYSLSF2060D SCREW,X2
110 LY20684-005A LOWER CASE ASSY,A,B,G
LY20684-022A LOWER CASE ASSY,C,D,E,F
LY20684-023A LOWER CASE ASSY,H,J
110A LY40081-001A CAP
110B LY20682-001A GRIP BELT
110C LY30018-003A SPECIAL SCREW
110D QAS0061-001 SPEAKER
110E LY42764-001B HOLDER(SPEAKER)
110F QYSLSF2050Z SCREW
111 LY31945-003A COVER(JACK)
112 LY31946-001A COVER(JIG)
113 QYSLSF2050Z SCREW,X3
114 QYSLSF2060D SCREW
115 QYSLSF2060D SCREW
116 QYSLSF2060D SCREW,X4
117 QYSLSF2060D SCREW,X2
118 QYSLSF2060D SCREW
125 LY20614-001C TOP OPE UNIT,F
LY20614-004C TOP OPE UNIT,A
LY20614-009C TOP OPE UNIT,H,J
LY20614-010C TOP OPE UNIT,B,C,G
LY20614-020B TOP OPE UNIT,D,E
126 QYSLSF2060D SCREW,X2
130 LY20615-005E REAR UNIT,A,B,C,D,E,F,G
LY20615-007B REAR UNIT,H
LY20764-010A REAR UNIT,J
131 QYSLSF2060D SCREW,X3
135 LY20683-034A FRONT COVER ASSY,B,C,G
LY20683-035A FRONT COVER ASSY,H,J
LY20683-038A FRONT COVER ASSY,A
LY20683-039A FRONT COVER ASSY,D,E
LY20683-054A FRONT COVER ASSY,F
135A LY31937-001A HOOD
135B LY31938-001A COVER(HOOD)
135C LY31936-001A RING
135D LY32482-001A MICROPHONE
135E QYSLSF2060D SCREW,X4
135F LY32040-001A DC LIGHT,B,C,D,E,F,G,H,J
LY30934-017A COVER(LIGHT),A
135G LY32058-001A STICKER(A),A
LY32058-002A STICKER(A),B,C,D,E,F,G
LY32058-003A STICKER(A),H,J
