SERVICE MANUAL
No. 86656
December 2001
SPECIFICATIONS
(The specifications shown pertain specifically to the model GR-SXM745)
COMPACT VHS CAMCORDER
Printed in Japan
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2001 VICTOR COMPANY OF JAPAN, LTD.
GR-SXM340U,SXM740U
No. 86656
GR-SXM340U,SXM740U
JVC SERVICE & ENGINEERING COMPANY OF AMERICA
DIVISION OF JVC AMERICAS CORP.
Head office
East Coast
Midwest
West Coast
Atlanta
Hawaii
:
:
:
:
:
:
1700 Valley Road Wayne, New Jersey 07470-9976
10 New Maple Avenue Pine Brook, New Jersey 07058-9641
705 Enterprise Street Aurora, Illinois 60504-8149
5665 Corporate Avenue Cypress, California 90630-0024
1500 Lakes Parkway Lawrenceville, Georgia 30043-5857
2969 Mapunapuna Place Honolulu, Hawaii 96819-2040
(973)317-5000
(973)396-1000
(630)851-7855
(714)229-8011
(770)339-2582
(808)833-5828
JVC CANADA INC.
Head office
Montreal
Vancouver
:
:
:
21 Finchdene Square Scarborough, Ontario M1X 1A7
16800 Rte Trans-Canadienne, Kirkland, Quebec H9H 5G7
13040 Worster Court Richmond, B.C. V6V 2B3
(416)293-1311
(514)871-1311
(604)270-1311
S40895-04
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design
and specifications subject to change without notice.
Camcorder
General
Format : S-VHS/VHS NTSC standard
Power source : DC 11 V (Using AC Adapter)
DC 6 V (Using battery pack)
Power consumption
Viewfinder on : 4.0 W
LCD monitor on : 4.5 W
Video light : 3.0 W
Signal system : NTSC-type
Video recording system
Luminance : FM recording
Color : Converted sub-carrier direct recording
Conforms to VHS standard
Cassette : / cassette
Tape speed
SP : 33.35 mm/sec. (1-5/16 ips)
EP : 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP : 40 minutes
EP : 120 minutes
(with TC-40 cassette)
Operating
temperature : 0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature
: –20°C to 50°C (–4°F to 122°F)
Weight : Approx. 930 g (2.1 lbs)
Dimensions : 200 mm x 112 mm x 118 mm
(W x H x D) (7-7/8" x 4-7/16" x 4-11/16")
(with the LCD monitor closed and with the viewfinder
fully tilted downward)
Pickup : 1/4" format CCD
Lens : F1.6, f = 3.9 mm to 62.4 mm,
16:1 power zoom lens with auto iris and macro control,
filter diameter 40.5 mm
Viewfinder : Electronic viewfinder with 0.5" black/white CRT
White balance
adjustment : Auto/Manual adjustment
Some accessories are not available in some areas. Please consult your
nearest JVC dealer for details on accessories and their availability.
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active
matrix system
Speaker : Monaural
Connectors
Video : 1 V (p-p
)
, 75 Ω unbalanced, analog output (via
Video output connector)
Audio : 300 mV (rms), 1 kΩ analog output
(via Audio output connector)
Digital : ø3.5 mm, 4-pole, mini-head jack
S-Video : Y : 1 V (p-p
)
, 75 Ω, analog output
C : 0.29 V (p-p
)
, 75 Ω, analog output
AC Adapter
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`,
50 Hz/60 Hz
Output : DC 11 V , 1 A
Optional Accessories
• Battery Packs BN-V12U, BN-V20U, BN-V400U
• A/V (Audio/Video) Cable
• Compact S-VHS ( ) Cassettes ST-C-40/30/20
• Compact VHS ( ) Cassettes TC-40/30/20
• Active Carrying Bag CB-V7U
To Next Page
