MAIN BOARD ASSEMBLY <01>
!
REF.
MODEL
GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U
No.
ITEM
PW1 MAIN BOARD ASSY YB10356-UK1-01 YB10356-UJ1-01 YB10356-UK1-01 YB10356UC1-01
IC105 IC(DIGITAL) TC7S66FU-X — TC7S66FU-X
IC1801 IR DETECT UNIT —— —PIC-26043S
IC4002 IC Z4C2973-32-X — Z4C2973-32-X
IC4701 IC — MM1512XN-X ——
I C4702 IC BA7665FS — BA7665FS
IC8001 IC MAX3221CAE — MAX3221CAE
Q3505 TRANSISTOR DTC144EE — DTC144EE
Q4001 TRANSISTOR DTC144EE — DTC144EE
D4001 DIODE DAN222 — DAN222
D8001 ZENER DIODE EMZ6.8N — EMZ6.8N
D8002 ZENER DIODE EMZ6.8N — EMZ6.8N
R182 MG RESISTOR NRSA63J-105X — NRSA63J-105X
R4013 MG RESISTOR NRSA63J-102X — NRSA63J-102X
R4014 MG RESISTOR NRSA63J-103X — NRSA63J-103X
R4712 MG RESISTOR NRSA63D-680X — NRSA63D-680X
R4713 MG RESISTOR NRSA63D-680X — NRSA63D-680X
R8001 MG RESISTOR NRSA63J-331X — NRSA63J-331X
R8002 MG RESISTOR NRSA63J-0R0X — NRSA63J-0R0X
R8003 MG RESISTOR NRSA63J-0R0X — NRSA63J-0R0X
C144 CAPACITOR — NDC31HJ-101X
C4006 CAPACITOR — NDC31HJ-100X ——
C4024 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C4025 CAPACITOR NCB31CK-104X — NCB31CK-104X
C4044 CAPACITOR NCB30JK-105X — NCB30JK-105X
C4713 E CAPACITOR NEA70JM-226X — NEA70JM-226X
C4714 E CAPACITOR NEA70GM-107X — NEA70GM-107X
C4715 CAPACITOR NCB31EK-103X — NCB31EK-103X
C8001 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C8002 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C8003 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C8004 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
C8005 CAPACITOR NBE20JM-106X — NBE20JM-106X
C8006 CAPACITOR NCF31EZ-104X — NCF31EZ-104X
L501 MG RESISTOR NRSA63J-0R0X — NRSA63J-0R0X
L8001 COIL NQL365K-220X — NQL365K-220X
J505 S JACK QND0068-001 — QND0068-001
MONITOR BOARD ASSEMBLY <07>
!
REF.
MODEL
GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U
No.
ITEM
PW MONITOR BOARD ASSY YB20913F YB20913E YB20913F
Q7607 TRANSISTOR DTC144EE ——DTC144EE
R7622 MG RESISTOR NRSA63J-0R0X ——NRSA63J-0R0X
R7647 MG RESISTOR — NRSA63J-0R0X —
R7648 MG RESISTOR NRSA63J-103X ——NRSA63J-103X
R7649 MG RESISTOR — NRSA63J-333X —
R7650 MG RESISTOR NRSA63J-103X ——NRSA63J-103X
Notes : Mark is same as left.
Mark — is not used.
