6 EN
1
2
3
4
3
4
2
1
Using the battery pack
1
Hook-on the battery pack’s top end to the
camcorder. (Charging procedure, 墌 pg. 10)
2 Push in the battery pack until it locks into
place.
To remove the battery pack
Slide BATT. RELEASE and pull out the battery
pack.
QUICK OPERATION GUIDE (VIDEO)
1 Set the System Select Switch to “VIDEO”.
2 Set the Power Switch to “PLAY”.
3 Press REW.
— The tape will automatically stop at the
beginning of the tape.
4 Press PLAY/PAUSE.
— Playback starts and the playback picture
appears.
•To stop playback, press STOP.
(For more details, 墌 pg. 42.)
•The viewfinder switches off automatically to
save power when the LCD monitor is opened
at an angle of over 45 degrees.
•The LCD monitor turns on/off when it is
opened/closed at approx. 45 degrees.
Or simply play back the tape on a VHS VCR
using the Cassette Adapter (VHS Playpak).
墌 pg. 45
1 Slide the LENS COVER Open/Close Switch
to open the lens cover.
2 Set the System Select Switch to “VIDEO”.
3 Set the Power Switch to “CAMERA”.
— The power indicator will light and an
image will appear.
4 Press the Recording Start/Stop Button.
— Recording starts.
•To stop recording temporarily, momentarily
press the Recording Start/Stop Button once
again.
(For more details, 墌 pgs. 18 – 21)
•The viewfinder switches off automatically to
save power when the LCD monitor is
opened at an angle of over 45 degrees.
•The LCD monitor turns on/off when it is
opened/closed at approx. 45 degrees.
SUPPLY POWER
INSERTING A VIDEO
CASSETTE
PLAYBACK
SHOOTING
1 Open the LCD monitor to an angle of over
45 degrees.
2 Press EJECT to open the cassette holder.
3 Insert a video cassette.
4 Press PUSH to close the cassette holder.
(For more details, 墌 pg. 17)
2
1
BATT. RELEASE
4
3
2
1
Hook on.
Push in.
EJECT
PUSH
Open
LENS COVER
Open/Close
Switch
Recording
Start/Stop
Button
Set to
“CAMERA”
Set to “VIDEO”
PLAY/PAUSE
STOP
REW
Set to “PLAY”
Set to
“VIDEO”
To Next Page
