EN
ENEN
EN

&
&&
&
Master Page: Right
Controls
a Snapshot Button [SNAPSHOT].......
pg. 23, 42
b Power Zoom Lever [T/W] ..................
pg. 18
Speaker Volume Control
[VOL. +, ] ........................................
pg. 20
c Power Switch [A, M, PLAY, OFF] ........
pg. 13
d Lock Button .........................................
pg. 13
e Diopter Adjustment Control ................
pg. 12
f Recording Start/Stop Button................
pg. 17
g Stop Button [8] .................................
pg. 20
Backlight Compensation Button
[BACK LIGHT]...................................
pg. 47
h Rewind Button [
3
]..........................
pg. 20
Focus Adjustment Button [FOCUS] ...
pg. 45
i Play/Pause Button [4/9] ..................
pg. 20
Exposure Button [EXPOSURE] ...........
pg. 46
j Fast-Forward Button [
5
] .................
pg. 20
Night-Alive Button [NIGHT]..............
pg. 42
k Battery Release Button
[BATT.RELEASE] ...................................
pg. 10
l VIDEO/MEMORY Switch
[VIDEO/MEMORY]..............................
pg. 13
m Menu Button [MENU]..........................
pg. 31
n E-Mail Clip Recording Button
[E-MAIL]............................................
pg. 50
Information Button [INFO]................
pg. 26
o Thumbnail Storing Button
[NAVI STORE]......................................
pg. 49
p Index Button [INDEX] .......................
pg. 26
Navigation Button [NAVI] .................
pg. 48
q •– Button.............................................
pg. 31
LCD Monitor Brightness Control
[MONITOR BRIGHT ] .....................
pg. 13
r + Button ............................................
pg. 31
LCD Monitor Brightness Control
[MONITOR BRIGHT +].....................
pg. 13
s D.S.C. Playback Select Button
[SELECT]....................................
pg. 24 29
Set Button [SET].................................
pg. 31
t Cassette Open/Eject Switch
[OPEN/EJECT]......................................
pg. 15
Connectors
The connectors are located beneath the covers.
U USB (Universal Serial Bus)
Connector............................................
pg. 66
V Digital Video Input/Output Connector [DV]
(i.Link*)....................................
pg. 53, 54, 66
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
W S-Video/Audio/Video Input/Output and Edit
Connector [S/AV] ....................
pg. 22, 52, 62
X DC Input Connector [DC] .............
pg. 10, 11
Indicators
C Power/Charge Lamp
[POWER/CHARGE] ..................
pg. 10, 13, 17
D Tally Lamp ................................
pg. 17, 37, 44
Other Parts
b Viewfinder............................................
pg. 12
c Shoulder Strap Eyelet .............................
pg. 7
d Battery Pack Mount..............................
pg. 10
e Grip Strap.............................................
pg. 12
f Speaker ................................................
pg. 20
g Stereo Microphone...............................
pg. 59
h Remote Sensor ...................................
pg. 56
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
i Flash Sensor
Be careful not to cover this area, as it cortains a
sensor required by the flash.
j Flash.....................................................
pg. 43
k LCD Monitor ..................................
pg. 12, 18
l Card Cover [MEMORY CARD] ............
pg. 16
m Stud Hole
n Tripod Mounting Socket .......................
pg. 12
o Monitor Latch ......................................
pg. 12
p Cassette Holder Cover..........................
pg. 15
REFERENCES
GR-D200US.book Page 81 Friday, April 11, 2003 1:05 PM
