Controls
a Menu Wheel [MMENU/VOL.] (墌 pg. 15)
Speaker Volume Control [MMENU/VOL.] (墌 pg. 13)
b Snapshot Button [SNAPSHOT] (墌 pg. 21)
c Power Zoom Lever [T/W] (墌 pg. 11)
d Manual Focus Button [FOCUS] (墌 pg. 22)
Blank Search Button [BLANK SRCH] (墌 pg. 13)
e Diopter Adjustment Control (墌 pg. 8)
f Recording Start/Stop Button (墌 pg. 10)
g Power Switch [A, M, PLAY, OFF] (墌 pg. 8)
h Lock Button (墌 pg. 8)
i Stop Button [8] (墌 pg. 13)
j Rewind Button [ 3 ] (墌 pg. 13)
Night Button [NIGHT] (墌 pg. 19)
k Play/Pause Button [4/9] (墌 pg. 13)
l Fast-Forward Button [ 5 ] (墌 pg. 13)
Backlight Compensation Button [BACKLIGHT]
(墌 pg. 23)
m Battery Release Switch [BATT.RELEASE] (墌 pg. 6)
n Cassette Open/Eject Switch [OPEN/EJECT] (墌 pg. 9)
o White LED Light Switch [LIGHT] (墌 pg. 19)
p Monitor Opening Button (墌 pg. 11)
For models without button, simply pull on bottom end
of LCD monitor to open.
Connectors
Q S-Video Output Connector [S-VIDEO] (墌 pg. 14, 24)
R Digital Video Connector [DV] (i.Link*) (墌 pg. 25, 26)
S Audio/Video Output Connector [AV] (墌 pg. 14, 24)
T DC Input Connector [DC] (墌 pg.6,7)
* i.Link refers to the IEEE1394-1995 industry specification
and extensions thereof. The logo is used for products
compliant with the i.Link standard.
Indicators
U POWER/CHARGE Lamp (墌 pg.8,10)
Other Parts
V Shoulder Strap Eyelet (墌 pg. 5)
W Battery Pack Mount (墌 pg. 7)
X Grip Strap (墌 pg. 7)
Y LCD Monitor (墌 pg. 11, 12)
Z Speaker (墌 pg. 13)
a Stud Hole (墌 pg. 9)
b Tripod Mounting Socket (墌 pg. 9)
c Cassette Holder Cover (墌 pg. 9)
d Stereo Microphone
e White LED Light (墌 pg. 19)
f Viewfinder (墌 pg. 8)
g Camera Sensor
(Be careful not to cover this area, a sensor necessary
for shooting is built-in here.)
