MONI-BW BOARD ASSEMBLY <02>
L6201 NQL52EM-390X COIL 39uH M
L6301 NQL52EM-390X COIL 39uH M
L6302 NQL144K-220X P COIL 22uH K
L6401 NQL52EM-470X COIL 47uH M
L6501 NQL52EM-470X COIL 47uH M
L6601 NQL52EM-221X COIL 220uH M
L6701 NQL73EM-100X COIL 10uH M
L6801 NQL034K-470X P COIL 47uH K
L8001 NQR0129-002X FERRITE BEADS
L8002 NQR0129-002X FERRITE BEADS
L8003 NQR0129-002X FERRITE BEADS
L8004 NQR0129-002X FERRITE BEADS
L8005 NQR0129-002X FERRITE BEADS
L8006 NQR0129-002X FERRITE BEADS
L8301 NQR0129-002X FERRITE BEADS
CN101 QGF0528F1-40X CONNECTOR FFC/FPC (1-40)
CN102 QGF0505F1-22X CONNECTOR FFC/FPC (1-22)
CN103 QGF0507F3-10X CONNECTOR FFC/FPC (1-10)
CN104 QGA1002C1-11X CONNECTOR W-B (1-11)
CN105 QGB0509M1-30X CONNECTOR B-B (1-30)
CN106 QGA1201C2-05X CONNECTOR W-B (1-5)
CN107 QGF0503C1-20X CONNECTOR FFC/FPC (1-20)
CN108 QGF0503C1-24V CONNECTOR FFC/FPC (1-24)
CN109 QGF0503F1-16X CONNECTOR FFC/FPC (1-16)
CN110 QGF0528F1-40X CONNECTOR FFC/FPC (1-40)
CN111 QGF0528F1-40X CONNECTOR FFC/FPC (1-40)
 F6001 NMFZ007-2R0X-K FUSE 2A 32V
 F6301 NMFZ007-1R25X-K FUSE 1.25A 32V
 F6701 NMFZ007-1R25X-K FUSE 1.25A 32V
 F6801 NMFZ007-R50X-K FUSE 0.5A 50V
J501 NNZ0041-001X D CONNECTOR IEEE1394(4pin)
J502 QNZ0616-001 USB CONNECTOR
X1001 NAX0578-001X CRYSTAL
X1002 NAX0564-001X CRYSTAL
X3002 NAX0480-001X CRYSTAL 24.576MHz
X5501 NAX0587-001X CXO
X8301 NAX0522-001X C RESONATOR 6.000MHz
OT1 LY30030-071A SPACER(A)
OT2 LY44158-001A SHEET(SHIELD)
WR1 QAL0474-001 FPC MAIN-PREMDA CN401
WR2 QAL0474-001 FPC MAIN-PREMDA CN408
 Symbol No. Part No. Part Name Description Local
PW1 YB10433F-01 MONI-BW BOARD ASSY
IC7601 AN12550A IC
IC7602 BA4558F-X IC
Q7601 2SC4617/QR/-X TRANSISTOR
Q7601 or 2SC4738/YG/-X TRANSISTOR
Q7601 or 2SD2216J/QR/-X TRANSISTOR
Q7601 or BC847BT-X TRANSISTOR
Q7602 2SA1774/QR/-X TRANSISTOR
Q7602 or 2SA1832/YG/-X TRANSISTOR
Q7602 or BC857BT-X TRANSISTOR
Q7603 2SC4617/QR/-X TRANSISTOR
Q7603 or 2SC4738/YG/-X TRANSISTOR
Q7603 or 2SD2216J/QR/-X TRANSISTOR
Q7603 or BC847BT-X TRANSISTOR
Q7604 2SA1774/QR/-X TRANSISTOR
Q7604 or 2SA1832/YG/-X TRANSISTOR
Q7604 or BC857BT-X TRANSISTOR
Q7608 DTC144EE-X DIGI TRANSISTOR
Q7608 or UN9213J-X DIGI TRANSISTOR
Q7608 or RN1104-X DIGI TRANSISTOR
Q7608 or BCR148T-X DIGI TRANSISTOR
Q7609 2SC4617/QR/-X TRANSISTOR
Q7609 or 2SC4738/YG/-X TRANSISTOR
Q7609 or 2SD2216J/QR/-X TRANSISTOR
Q7609 or BC847BT-X TRANSISTOR
Q7610 DTA114EE-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q7610 or BCR183T-X DIGI TRANSISTOR
Q7611 DTC144EE-X DIGI TRANSISTOR
Q7611 or UN9213J-X DIGI TRANSISTOR
Q7611 or RN1104-X DIGI TRANSISTOR
Q7611 or BCR148T-X DIGI TRANSISTOR
Q7612 DTA144EE-X DIGI TRANSISTOR
Q7612 or UN9113J-X DIGI TRANSISTOR
Q7612 or RN2104-X DIGI TRANSISTOR
Q7612 or BCR198T-X DIGI TRANSISTOR
Q7613 2SD2654/VW/-X TRANSISTOR
D11 RSA6.1J4-W SI DIODE
D7602 1SS355-X SI DIODE
C1 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C10 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C11 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7601 NCB21CK-105X C CAPACITOR 1uF 16V K
C7602 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7603 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7604 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7605 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7606 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7607 NCB41CK-106X C CAPACITOR 10uF 16V K
C7608 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7609 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7613 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7614 NCB31HK-152X C CAPACITOR 1500pF 50V K
C7615 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7616 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7617 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7618 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C7619 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C7620 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7621 NCB21CK-105X C CAPACITOR 1uF 16V K
C7622 NCB21CK-105X C CAPACITOR 1uF 16V K
C7623 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C7624 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7626 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7627 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C7628 NBP41EM-475X TA E CAPACITOR 4.7uF 25V M
C7629 NBP21CM-335X TA E CAPACITOR 3.3uF 16V M
C7630 NBP41EM-475X TA E CAPACITOR 4.7uF 25V M
C7631 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7632 NBP41EM-475X TA E CAPACITOR 4.7uF 25V M
C7633 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7634 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7635 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7637 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7646 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7647 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7651 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C7661 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7662 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7664 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7665 NBP41CM-226X TA E CAPACITOR 22uF 16V M
C7666 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R3 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R5 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R6 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R7 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R18 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R19 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R21 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R22 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R23 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R25 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R29 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R30 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R31 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R32 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7601 NRVA63D-622X CMF RESISTOR 6.2k Ω 1/16W D
R7602 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R7603 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D70EK A
GR-D70EX B
MODEL MARK
GR-D70EY C
GR-D70EZ D
