(No.86733)3-17
BL-2.5 BOARD ASSEMBLY <03>
CCD BOARD ASSEMBLY <04>
PREMDA BOARD ASSEMBLY <05>
R7608 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7609 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R7610 NRVA63D-433X CMF RESISTOR 43k Ω 1/16W D
R7611 NRVA63D-821X CMF RESISTOR 820 Ω 1/16W D
R7612 NRVA63D-223X CMF RESISTOR 22k Ω 1/16W D
R7613 NRVA63D-223X CMF RESISTOR 22k
Ω 1/16W D
R7614 NRVA63D-223X CMF RESISTOR 22k
Ω 1/16W D
R7615 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7616 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7617 NRSA02J-561X MG RESISTOR 560 Ω 1/10W J
R7618 NRSA02J-561X MG RESISTOR 560 Ω 1/10W J
R7620 NRSA63J-335X MG RESISTOR 3.3M Ω 1/16W J
R7621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7630 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7634 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7636 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7637 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7638 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7661 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7662 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7663 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R7666 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R7667 NRVA63D-273X CMF RESISTOR 27k Ω 1/16W D
R7668 NRVA63D-273X CMF RESISTOR 27k Ω 1/16W D
R7669 NRVA63D-392X CMF RESISTOR 3.9k Ω 1/16W D
R7672 NRSA63D-394X MG RESISTOR 390k Ω 1/16W D
R7673 NRVA63D-473X CMF RESISTOR 47k Ω 1/16W D
R7674 NRVA63D-473X CMF RESISTOR 47k Ω 1/16W D
R7675 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
L10 NQR0129-002X FERRITE BEADS
L7601 NQL365K-100X COIL 10uH K
L7602 NQL365K-470X COIL 47uH K
L7603 NQL365K-470X COIL 47uH K
L7604 NQL365K-100X COIL 10uH K
L7605 NQL365K-100X COIL 10uH K
L7607 NQL365K-100X COIL 10uH K
CN761 QGF0508F1-40X CONNECTOR FFC/FPC (1-40)
CN762 QGF0508F1-10X CONNECTOR FFC/FPC (1-10)
CN763 QGF0507F3-20X CONNECTOR FFC/FPC (1-20)
CN765 QGF0506F2-32X CONNECTOR FFC/FPC (1-32)
CN766 NNZ0058-001X SD CARD CONNECTOR
SW2 NSW0145-001X TACT SWITCH STOP
SW3 NSW0145-001X TACT SWITCH REW
SW4 NSW0145-001X TACT SWITCH FF
SW5 NSW0145-001X TACT SWITCH PLAY/PAUSE
SW6 NSW0099-001X SLIDE SWITCH DSC/VIDEO
SW7 NSW0145-001X TACT SWITCH INDEX
SW8 NSW0145-001X TACT SWITCH SELECT
SW7601 NSW0200-001X LEVER SWITCH MONI SW
OT1 LY44158-001A SHEET(SHIELD)
 Symbol No. Part No. Part Name Description Local
PW1 YB20938A BL-2.5 BOARD ASSY
IC7604 DN8797MS-X IC
Q7501 2SD1664/QR/-W TRANSISTOR
Q7502 2SD1664/QR/-W TRANSISTOR
Q7503 DTA144EE-X DIGI TRANSISTOR
Q7503 or UN9113J-X DIGI TRANSISTOR
Q7503 or RN2104-X DIGI TRANSISTOR
Q7503 or BCR198T-X DIGI TRANSISTOR
Q7504 DTC144EE-X DIGI TRANSISTOR
Q7504 or UN9213J-X DIGI TRANSISTOR
Q7504 or RN1104-X DIGI TRANSISTOR
Q7504 or BCR148T-X DIGI TRANSISTOR
C7501 NCZ1016-120X C CAPACITOR 12pF 2kV J
C7502 NCB21EK-273X C CAPACITOR 0.027uF 25V K
C7503 NCB31EK-103X C CAPACITOR 0.01uF 25V K
 Symbol No. Part No. Part Name Description Local
C7504 NCB10JK-106X C CAPACITOR 10uF 6.3V K
R7501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7504 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7511 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7512 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7513 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7501 NQLZ010-680X COIL 68uH M
 T7501 NQS0056-001X SW TARNSF
CN7601 QGF0507F3-16X CONNECTOR FFC/FPC (1-16)
CN7602 QGF0507F3-16X CONNECTOR FFC/FPC (1-16)
CN7603 QGF0508F1-24X CONNECTOR FFC/FPC (1-24)
 F7501 NMFZ007-R40X-K FUSE 0.4A 50V
WR1 QAL0464-001 FPC
 Symbol No. Part No. Part Name Description Local
PW1 YB10406A-01-SS CCD BOARD ASSY
Q5001 2SC3931/CD/-X TRANSISTOR
Q5002 2SC4081/QR/-X TRANSISTOR
Q5002 or BC847BW-X TRANSISTOR
C5001 NBP41EM-475X TA E CAPACITOR 4.7uF 25V M
C5002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5003 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C5004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5006 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5007 NCB31EK-222X C CAPACITOR 2200pF 25V K
R5001 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5002 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5005 NRS181J-472X MG RESISTOR 4.7k Ω 1/8W J
L5001 NQL144K-100X P COIL 10uH K
L5002 NQL315K-100X COIL 10uH K
 Symbol No. Part No. Part Name Description Local
PW1 YB10405A-01 PREMDA BOARD ASSY
IC1601 BD6637KS IC
IC1701 LM358DMR2-X IC
IC1702 LM393DMR2-X IC
IC3501 JCY0132 IC
IC3502 SN74AHC1G04K-X IC
Q1601 UMC3N-W DIGI TRANSISTOR
D1602 DAP222-X DIODE ARRAY
D1602 or MA132WA-X SI DIODE
D1603 DAP222-X DIODE ARRAY
D1603 or MA132WA-X SI DIODE
D1604 DAP222-X DIODE ARRAY
D1604 or MA132WA-X SI DIODE
C1601 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1602 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1606 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1607 NCB31CK-473X C CAPACITOR 0.047uF 16V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D70EK A
GR-D70EX B
MODEL MARK
GR-D70EY C
GR-D70EZ D
