3-18(No.86733)
JACK BOARD ASSEMBLY <06>
C1614 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1618 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1619 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1620 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1621 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1622 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1623 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C1624 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1625 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1626 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1627 NCB31HK-822X C CAPACITOR 8200pF 50V K
C1628 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1629 NBP41DM-106X TA E CAPACITOR 10uF 20V M
C1630 NCB21CK-334X C CAPACITOR 0.33uF 16V K
C1632 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C1633 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1641 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3501 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3502 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3503 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C3504 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3505 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C3506 NCB21AK-105X C CAPACITOR 1uF 10V K
C3507 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3508 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3509 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3510 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3511 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3512 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3513 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3514 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3515 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3516 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C3517 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3518 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3519 NCB31HK-102X C CAPACITOR 1000pF 50V K
C3520 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3521 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3522 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C3523 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3524 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3525 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C3526 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C3527 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3528 NCB31EK-103X C CAPACITOR 0.01uF 25V K
R1601 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R1602 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R1603 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1604 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1610 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1611 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1612 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1613 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1614 NRZ0072-R330X MG RESISTOR 0.33 Ω 1/4W F
R1616 NRSA63D-332X MG RESISTOR 3.3k
Ω 1/16W D
R1617 NRZ0072-R330X MG RESISTOR 0.33 Ω 1/4W F
R1620 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1621 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1622 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1624 NRSA63D-183X MG RESISTOR 18k
Ω 1/16W D
R1625 NRSA63D-361X MG RESISTOR 360
Ω 1/16W D
R1629 NRSA63J-564X MG RESISTOR 560k Ω 1/16W J
R1630 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1631 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1635 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R1636 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R1637 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R1638 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1639 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1640 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1641 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1642 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1648 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1701 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1702 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R1703 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1704 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1705 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1706 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1708 NRSA63J-124X MG RESISTOR 120k
Ω 1/16W J
R1709 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1710 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1711 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1712 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3501 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3502 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3504 NRSA63D-241X MG RESISTOR 240 Ω 1/16W D
R3505 NRSA63D-241X MG RESISTOR 240 Ω 1/16W D
R3506 NRSA63D-241X MG RESISTOR 240 Ω 1/16W D
R3507 NRSA63D-241X MG RESISTOR 240 Ω 1/16W D
R3508 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3511 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
L3501 NQR0006-001X FERRITE BEADS
L3502 NQL402M-100X COIL 10uH M
L3503 NQR0006-001X FERRITE BEADS
L3504 NQR0006-001X FERRITE BEADS
L3505 NQR0006-001X FERRITE BEADS
CN401 QGF0528F1-40X CONNECTOR FFC/FPC (1-40)
CN402 QGF0517F1-08X CONNECTOR FFC/FPC (1-8)
CN403 QGF0505F2-06X CONNECTOR FFC/FPC (1-6)
CN404 QGF0507F3-11X CONNECTOR FFC/FPC (1-11)
CN405 QGF0507F3-18X CONNECTOR FFC/FPC (1-18)
CN406 QGF0503F4-16X CONNECTOR FFC/FPC (1-16)
CN407 QGF0508F1-06X CONNECTOR FFC/FPC (1-6)
CN408 QGF0528F1-40X CONNECTOR FFC/FPC (1-40)
 F1601 NMFZ007-R20X-K FUSE 0.2A 50V
 F1602 NMFZ007-R50X-K FUSE 0.5A 50V
OT1 LY33021-001A S.COVER(P/R)
 Symbol No. Part No. Part Name Description Local
PW1 YB20943B-01 JACK BOARD ASSY
IC501 BA10358F-XE IC
IC502 RPM7138-V4 IR DETECT UNIT
Q501 RPM-22PB PHOTO TRANSISTOR
D501 SML-010LT-X LED
D503 MA8068-X Z DIODE
D506 MA8068-X Z DIODE
D507 EMZ6.8N-X Z DIODE
C501 NBE21AM-335X TA E CAPACITOR 3.3uF 10V M
C502 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C503 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C504 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C506 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C509 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C512 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R501 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R502 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R503 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R504 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R505 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R506 NRSA63J-824X MG RESISTOR 820k
Ω 1/16W J
R507 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R508 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R509 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R510 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R511 NRSA63J-302X MG RESISTOR 3k Ω 1/16W J
R512 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D70EK A
GR-D70EX B
MODEL MARK
GR-D70EY C
GR-D70EZ D
