(No.86733)3-19
B/W-VF BOARD ASSEMBLY <07>
R513 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R514 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R515 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R516 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R517 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R518 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R519 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R520 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R521 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R522 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R523 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
L501 NQR0251-004X FERRITE BEADS
L502 NQR0251-004X FERRITE BEADS
L503 NQR0251-004X FERRITE BEADS
CN501 QGF0503C1-22X CONNECTOR FFC/FPC (1-22)
J501 QNS0078-001 3.5 JACK
J502 QND0004-001 S JACK
J503 PEMC1203 MINI JACK
SW501 NSW0122-001X DETECT SWITCH EJECT SW
 Symbol No. Part No. Part Name Description Local
PW1 YB20940A B/W-VF BOARD ASSY
Q7001 PUMX1-W PAIR TRANSISTOR
Q7001 or BC847S-X PAIR TRANSISTOR
D7001 E1S35AW0C501-X LED
C7001 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R7001 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R7002 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R7003 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R7004 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
CN7001 QGF0532F1-18X CONNECTOR FFC/FPC (1-18)
CN7002 QGF0507F3-20X CONNECTOR FFC/FPC (1-20)
 Symbol No. Part No. Part Name Description Local
(WPC)-200304
E. & O.E. No.86733 (WPC)-M3D127 GR-D70EK,GR-D70EX,GR-D70EY,GR-D70EZ
MODEL MARK
GR-D70EK A
GR-D70EX B
MODEL MARK
GR-D70EY C
GR-D70EZ D
