EN61
5m
30°
30°
1
3
2
+
–
+
–
The Full-Function Remote Control Unit can operate this
camcorder from a distance as well as the basic operations
(Playback, Stop, Pause, Fast-Forward and Rewind) of your
VCR. It also makes additional playback functions possible.
Installing The Batteries
The remote control uses two “AAA (R03)” size batteries.
See “General Battery Precautions” ( pg. 89).
1
Remove the battery compartment cover while
pushing up the tab as illustrated.
2
Insert two “AAA (R03)” size batteries in the correct
direction.
3
Re-attach the battery compartment cover.
USING THE REMOTE CONTROL UNIT
When using the remote control, be sure to point
it at the remote sensor. The illustration shows the
approximate transmitted beam effective area for
indoor use.
The transmitted beam may not be effective or
may cause incorrect operation outdoors or when
the remote sensor is directly exposed to sunlight
or powerful lighting.
Transmitted beam
effective area
Remote sensor
Tab
To Next Page
