Jack Box
1 DC Input Connector [DC IN] ................. 墌 pg. 7
2 USB (Universal Serial Bus) Connector ... 墌 pg. 54
3 S-Video Input/Output Connector
[S-VIDEO] .................... 墌 pg. 52, 53, 56, 57, 66
4 Edit Connector [EDIT] .......................... 墌 pg. 66
Connect the editing cable when performing
Random Assemble Editing ........... 墌 pg. 65 – 70
1
3
2
4
5
5 Multi Connector
The Jack Box can be connected with this
camcorder through this connector. Never touch it
with your hand or hit it with a hard object; if the
pins are damaged, the connectors will become
unusable due to contact failure.
To Next Page
