Controls
1 FOCUS Button ..................................... 墌 pg. 25
2 Snapshot Button
[SNAPSHOT] ................ 墌 pg. 18, 19, 22, 24, 60
3 •Power Zoom Lever [T/W] .................. 墌 pg. 20
•Speaker/Headphone Volume Control
[VOLUME]........................................ 墌 pg. 38
4 Shooting Mode Switch
[VIDEO, XGA/VGA, UXGA] ................ 墌 pg. 12
5 Power Switch [ , , , OFF] ...... 墌 pg. 12
6 Recording Start/Stop Button .................. 墌 pg. 16
7 Lock Button ......................................... 墌 pg. 12
8 Diopter Adjustment Control ................... 墌 pg. 8
9 MEMORY PLAY Button ........................ 墌 pg. 42
0 •Stop Button [5] ................................. 墌 pg. 38
•BACKLIGHT Button .......................... 墌 pg. 36
! •Rewind Button [ 2 ] ......................... 墌 pg. 38
•EXPOSURE Button ............................ 墌 pg. 36
@ •Play/Pause Button [ 4 /6] ................... 墌 pg. 38
•Programme AE Button [PROG.AE] ..... 墌 pg. 34
# •Fast-Forward Button [ 3 ] ................. 墌 pg. 38
•FADE/WIPE Button ............................ 墌 pg. 32
$ INDEX Button ...................................... 墌 pg. 43
% BLANK SEARCH Button ....................... 墌 pg. 41
^ PRINT FRAME Button .......................... 墌 pg. 46
& PRINT Button
Enables printing using the optional printer
equipped with a PRINT DATA connector. Refer to
the separate “FOR OWNERS OF AN OPTIONAL
PRINTER” instruction sheet.
* Monitor Open Button [PUSH OPEN] ... 墌 pg. 16
( •MENU Wheel [ , , PUSH] ............ 墌 pg. 26
•LCD Monitor Brightness Control ........ 墌 pg. 16
) Manual Focus Ring .............................. 墌 pg. 25
q Battery Release Button
[BATT. RELEASE] .................................... 墌 pg. 7
w OPEN/EJECT Switch ............................. 墌 pg. 10
Connectors
e External Stereo Microphone Input Connector
[MIC] .................................................. 墌 pg. 71
The connectors r to y are located beneath a cover.
r Headphone Connector [PHONE] ......... 墌 pg. 71
No sound is output from the speaker when
headphones are connected to this connector.
t PRINTER Connector
Connect to the optional printer equipped with a
PRINT DATA connector. Refer to the separate
“FOR OWNERS OF AN OPTIONAL PRINTER”
instruction sheet.
y Audio/Video Input/Output Connector
[AV] ............................. 墌 pg. 52, 53, 56, 57, 66
To connect a cable to the connector u , open the
LCD monitor.
u Digital Video Connector
[DV IN/OUT] (i.Link*) ........ 墌 pg. 54, 55, 58, 59
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
i Multi Connector
When attaching the Jack Box to the camcorder,
this part is connected.
Indicators
o Power Lamp ........................................ 墌 pg. 16
p Tally Lamp ........................................... 墌 pg. 16
Other Parts
Q Speaker ............................................... 墌 pg. 38
W Grip Strap .............................................. 墌 pg. 8
E Shoulder Strap Eyelets ............................ 墌 pg. 8
R Viewfinder Cleaning Hatch .................. 墌 pg. 80
T Battery Pack Mount ............................... 墌 pg. 7
Y LCD Monitor ................................. 墌 pg. 16, 17
U Lens Hood ............................................. 墌 pg. 4
I Lens Cover
Opens when the viewfinder is pulled out or the
LCD monitor is opened fully.
O Info-Shoe
Attach the optional video light/flash/zoom
microphone.
P Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
a Viewfinder ............................................. 墌 pg. 8
s Remote Sensor ..................................... 墌 pg. 61
d Stereo Microphone .............................. 墌 pg. 71
f Stud Hole .............................................. 墌 pg. 8
g Tripod Mounting Socket ......................... 墌 pg. 8
h MEMORY CARD Cover ....................... 墌 pg. 11
