JVC GR-DV2000 - For Connectors; AC Power Adapter;Charger; Jack Box CU-V504 U

EN95
For Connectors
AV
Video output :1 V ( p-p ) , 75 Ω, analogue
Video input : 0.5 V ( p-p ) – 2.0 V ( p-p ) , 75 Ω, analogue
Audio output : 308 mV (rms), 1 kΩ, analogue, stereo
Audio input : 308 mV (rms), 50 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
PHONE
Headphone output : ø3.5 mm, stereo
MIC
External microphone input : 459 µV (rms), high impedance unbalanced, ø3.5 mm (stereo)
PRINTER : For an optional video printer equipped with a PRINT DATA
connector
AC Power Adapter/Charger
AA-V40EA, AA-V40A, AA-V40A-S, AA-V40SH or AA-V40ED
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V , 1.2 A
VTR : DC 6.3 V , 1.8 A
Dimensions (W x H x D) : 68 mm x 38 mm x 110 mm
Weight
AA-V40EA : Approx. 270 g
AA-V40A/A-S/SH/ED : Approx. 260 g
Jack Box CU-V504U
For General
Dimensions (W x H x D) : 37.5 mm x 18.5 mm x 55 mm
Weight : Approx. 30 g
For Connectors
USB : TYPE B
S-VIDEO : Y: 1 V (p-p), 75 Ω, analogue output
C: 0.29 V (p-p), 75 Ω, analogue output
EDIT : ø3.5 mm, 2-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
