EN
83
Controls
1 Snapshot Button
[SNAPSHOT] ............................. pg. 20, 21, 61
2 Power Zoom Lever [T/W] ..................... pg. 22
Speaker/Headphone Volume Control
[VOLUME] ........................................... pg. 25
3 Power Switch [ , , , OFF]....... pg. 14
4 Recording Start/Stop Button .................. pg. 18
5 Lock Button ............................................ pg. 14
6 Dioptre Adjustment Control ................... pg. 10
7 Stop Button [5] .................................... pg. 25
Programme AE Button [PROG.AE] ..... pg. 38
8 Rewind Button [
2
] ............................. pg. 25
NIGHT Button ...................................... pg. 38
9 Play/Pause Button [
4
/6] ..................... pg. 25
BACKLIGHT Button ............................. pg. 40
0 Fast-Forward Button [
3
] .................... pg. 25
FADE/WIPE Button.............................. pg. 36
! VIDEO/MEMORY Switch
[VIDEO, MEMORY]................................ pg. 14
@ TITLE Button ......................................... pg. 48
# INDEX Button ............................ pg. 27, 45, 48
$ NAVI Button ......................................... pg. 42
SELECT Button ..................... pg. 26, 49 53
% E-MAIL Button ..................................... pg. 46
INFO Button......................................... pg. 27
^ D. SOUND Button .................................. pg. 45
& Monitor Open Button [PUSH OPEN] ..... pg. 18
* FOCUS Button....................................... pg. 24
( EXPOSURE Button ............................... pg. 40
) MENU Wheel [, , PUSH]................ pg. 28
LCD Monitor Brightness Control .......... pg. 18
q Manual Focus Ring ................................ pg. 24
w Battery Release Switch
[BATT. RELEASE] .................................... pg. 9
e OPEN/EJECT Switch ............................ pg. 12
Connectors
The connectors r to y are located beneath a cover.
r Headphone Connector [PHONE]........... pg. 72
No sound is output from the speaker when
headphones are connected to this connector.
t PRINTER Connector
Connect to the optional printer equipped with a
PRINT DATA connector. Refer to the separate
FOR OWNERS OF AN OPTIONAL PRINTER
instruction sheet.
y Audio/Video Input/Output Connector
[AV] ............................................ pg. 54, 59, 67
To connect a cable to the connector u, open the LCD
monitor.
u Digital Video Connector
[DV IN/OUT] (i.Link*) ................. pg. 56, 58, 60
*i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
i Multi Connector
When attaching the Jack Box to the camcorder,
this part is connected.
Indicators
o Power Lamp ........................................... pg. 18
p Tally Lamp ............................................. pg. 18
Other Parts
Q Speaker ................................................. pg. 42
W Grip Strap .............................................. pg. 10
E Shoulder Strap Eyelets .......................... pg. 10
R Viewfinder Cleaning Hatch .................... pg. 80
T Battery Pack Mount ................................. pg. 9
Y LCD Monitor .................................... pg. 18, 19
U Lens Hood ............................................... pg. 6
I Info-Shoe
Attach the optional video light/flash/zoom
microphone.
O Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
P Viewfinder .............................................. pg. 10
a Remote Sensor...................................... pg. 62
s Stereo Microphone ................................ pg. 72
d Stud Hole ............................................... pg. 10
f Tripod Mounting Socket ......................... pg. 10
g MEMORY CARD Cover ......................... pg. 13
