1-3
1
ZOOM OPE UNIT Fig.1-3-1 3(S1),(L1a),5(L1b),CN1a-
2
FRONT COVER Fig.1-3-2a CN2a,CN2b,2(S2a),(S2b), NOTE2a
ASSY (S2c),(S2d),2(S2e),CN2c NOTE2b
NOTE2c
NOTE2d
FRONT BOARD ASSY
Fig1-3-2b (S2f),CN2d,CN2e NOTE2e
FE SW BOARD ASSY
2(S2f),CN2h NOTE2f
JUNCTION BOARD
(S2g),2(L2),2(S2f),
ASSY CN2f,CN2g
SHOE ASSY Fig1-3-2c (S2h)
SW FPC UNIT (S2f),COVER(MENU),(S2f)
FOUCUS UNIT 2(S2h),SPACER
MICROPHONE 2(S2j)
3
UPPER CASE ASSY
Fig.1-3-3 3(S3a),6(S3b),(S3c),CN3a NOTE3a
Inc.MONITOR ASSY
NOTE3b
NOTE3c
4 OP BLOCK ASSY Fig.1-3-4 CN4a,CN4b,CN4c, NOTE4
2(S4),(L4a),(L4b)
5
DSC BOARD ASSY
Fig.1-3-5 (L5),CN5a,CN5b NOTE5
6
REAR COVER ASSY
Fig.1-3-6 CN6a,2(S6a),(S6b) -
7 E.VF ASSY Fig.1-3-7 CN7a,(S7a),2(S7b),(L7a), NOTE7
(L7b),2(L7c)
8
LOWER CASE ASSY
Fig.1-3-8 CN8a,CN8b,3(S8a),(S8b), -
2(L8a),(L8b)
9
MAIN BOARD ASSY
Fig.1-3-9 CN9a,(S9),(L9)
0 PRE/MDA BOARD Fig.1-3-10 3(S0a),BKT(MECHA)ASSY, NOTE0a
/ ASSY, 2(S0b), NOTE0b
!
MECHANISM ASSY
SHIELD COVER(PRE/REC),
(L0),CN0a,CN0b,CN0c,
CN0d,CN0e,CN0f
3(S0b)
STEP
No.
PART
Fig.No.
POINT NOTE
1.3.2 Disassembly method
Table 1-3-2
CONN.
No.
Pin No.
CONNECTOR
Table 1-3-3
Note:
Remove the parts marked in .
CN1a JUNCTION CN1102 ⇔ ZOOM OPE UNIT – 8
CN2a JUNCTION CN1101 ⇔ MAIN CN112 16
CN2b MAIN CN103 ⇔ SHOE ASSY – 16
CN2c FRONT CN2413 ⇔ EJECT CN2411 6
CN2d FRONT CN2412 ↔ MICROPHONE – 3
CN2e FRONT CN2411 ⇔ SW FPC UNIT – 6
CN2f JUNCTION CN1104 ⇔ FOCUS UNIT – 6
CN2g JUNCTION CN1105 ↔ MICROPHONE – 3
CN2h FE SW CN1181 ↔ JUNCTION CN1103 3
CN3a MAIN CN108 MONITOR – 50
CN4a MAIN CN101 ↔ CCD – 2
CN4b MAIN CN102 ⇔ CCD – 20
CN4c MAIN CN104 ⇔ OP BLOCK ASSY – 24
CN5a DSC CN8401 MAIN CN105 80
CN5b DSC CN8402 ⇔ JACK CN301 20/45
CN6a MAIN CN109 REG CN601 80
CN7a MAIN CN110 ⇔
E.VF ASSY(VF BL)
CN501 22
CN8a EJECT CN2422 ⇔ MAIN CN113 6
CN8b JACK CN301 ⇔ MAIN CN111 24/45
CN9a MAIN CN106 PRE/MDA CN401 80
CN0a PRE/MDA CN406 ⇔ SENSOR – 16
CN0c PRE/MDA CN404 ⇔ DRUM MOTOR – 11
CN0d PRE/MDA CN402 ⇔ HEAD – 8
CN0e PRE/MDA CN407 ⇔
ROTARY ENCODER
– 6
CN0f PRE/MDA CN403 ⇔
LOADING MOTOR
– 6
NOTE
2
a:
Open the cassette cover after removing the
screws.
NOTE
2
b:
Be sure to confirm the position of the screws.
NOTE
2
c:
Be careful not to damage the FPC when unplug-
ging it.
NOTE
2
d:
As the
7
OP Block Assembly is exposed as a
result of the above steps, be careful not to dam-
age any of its parts. Take particular care not to
scratch the lens surfaces.
NOTE
2
e:
Treat the microphone wire with care.
NOTE
2
f:
When mounting, be careful not to damage the
switches.
NOTE
3
a/
3
b:
Be sure to confirm the position of the screws.
NOTE
3
c:
For the disassembly of the
@
Monitor Assem-
bly, see section 1.6, “Disassembly/Assembly of
@
Monitor Assembly”.
NOTE
4
:
For the disassembly of the
4
OP block assem-
bly, see section 1.4, “Disasembly/Assembly of
4
OP block assembly.
NOTE
5
:
Be careful not to damage the CONNECTOR.
NOTE
7
:
For the disassembly of the
7
E.VF, see section
1.4, “Disassembly/Assembly of
7
E.VF”.
NOTE
0
a:
The FPC of the loading motor should be
mounted by inserting it between the Mechanism
Assembly and the PRE/MDA Board Assembly.
NOTE
0
b:
When mounting the shield cover, push down the
FPC of the drum while attaching it.
To Next Page
