SPECIFICATIONS
Camcorder
For General
Power supply : DC 11 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 3.7 W
LCD monitor on, viewfinder off : Approx. 4.8 W
Dimensions (W x H x D) : 74.5 mm x 91 mm x 185 mm (2-15/16" x 3-5/8" x 7-5/16")
(with the LCD monitor closed and the viewfinder pushed back in)
Weight : Approx. 610 g (1.4 lbs) (GR-DV900/800)
Approx. 575 g (1.3 lbs) (GR-DV500)
(without cassette, memory card and battery)
Approx. 690 g (1.6 lbs) (GR-DV900)
Approx. 680 g (1.5 lbs) (GR-DV800)
Approx. 640 g (1.5 lbs) (GR-DV500)
(incl. cassette, memory card and battery)
Operating temperature : 0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Pickup : 1/4" CCD
Lens : F 1.2, f = 3.8 mm to 38 mm, 10:1 power zoom lens (GR-DV900)
F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens (GR-DV800/500)
Filter diameter : ø52 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DV900/800)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DV500)
Viewfinder : Electronic viewfinder with 0.24" color LCD
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : NTSC standard
Recording/Playback format : Video : Digital component recording
Audio : PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz
2-channel (16-bit)
Cassette : Mini DV cassette
Tape sp eed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time
(using 80 min. cassette)
: SP: 80 min.
LP: 120 min.
