JVC GR-DVA10 Technical Guide

2-19
•
••
•
Camera DSP (IC4301: JCY0120) pin functions (4/6)
Pin No. Label In/Out Description
99 CSYNC Out Internal composite sync. Signal output
238 ADDVSS - Ground for add Digital
174 DYO0
18 DYO1
19 DYO2
240 DYO3
239 VSS - Ground for Digital
243 VDDI - Power supply for Digital (I/O, internal)
16 DCO0
17 DCO1
97 DCO2
98 DCO3
173 INH Out Horizontal reference pulse output for DVC REC
172 INV Out Vertical reference pulse output for DVC REC
13 DYI0
14 DYI1
169 DYI2
12 DYI3
277 VDDI - Power supply for Digital (I/O, internal)
244 VSS - Ground for Digital
95 DCI0
170 DCI1
94 DCI2
11 DCI3
171 OUTH In Horizontal reference pulse input for DVC PB
96 OUTV In Vertical reference pulse input for DVC PB
241 VDDE - Power supply for Digital (I/O)
203 MCLK Out Clock output for field memory
49 IE1 Out Input enable
130 FMWE1 Out Memory write enable
48 WAD Out Write address
200 RAD Out Read address
201 FMRE1 Out Memory read enable
50 RAE1 Out Read address enable
129 FMWR Out Memory write transfer
265 WAE1 Out Write address enable
258 VDDI - Power supply for Digital (I/O, internal)
259 VSS - Ground for Digital
206 ADDVDDE - Power supply for add Digital (I/O)
51 IE2
131 FMWE2
202 FMRE2
52 RAE2
53 WAE2
134 TMY0
205 TMY1
56 TMY2
55 TMY3
Not used-
In Digital luminance signal input for DVC
In Digital colon difference signal input for DVC
Out Digital luminance signal output for DVC
Out Digital luminance signal output for field memory
Out Digital colon difference signal output for DVC
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (4/6)
