JVC GR-DVA10 Technical Guide

2-20
•
••
•
Camera DSP (IC4301: JCY0120) pin functions (5/6)
Pin No. Label In/Out Description
204 TMY4
133 TMY5
54 TMY6
132 TMY7
135 TMC0
58 TMC1
268 TMC2
57 TMC3
47 ADDVDDE - Power supply for add Digital (I/O)
128 ADDVSS - Ground for add Digital
261 FMY0
197 FMY1
260 FMY2
196 FMY3
195 FMY4
194 FMY5
193 FMY6
257 FMY7
199 FMC0
46 FMC1
127 FMC2
198 FMC3
262 VDDI - Power supply for Digital (I/O, internal)
236 VDDE - Power supply for Digital (I/O)
237 VDDI - Power supply for Digital (I/O, internal)
43 VSS - Ground for Digital
190 ADDVDDE - Power supply for add Digital (I/O)
44 CLK27
42 CLK18
45 CLK13
123 ID In Line discriminate pulse input
189 VDTG Out Vertical reference pulse output for TG
116 HDTG Out Horizontal reference pulse output for TG
253 LHFO Out LHF signal output
86 ADDVDDE - Power supply for add Digital (I/O)
264 VSS - Ground for Digital
118 ADIN9
37 ADIN8
119 ADIN7
38 ADIN6
120 ADIN5
39 ADIN4
121 ADIN3
40 ADIN2
122 ADIN1
41 ADIN0
232 VDDI - Power supply for Digital (I/O, internal)
7 ADDVSS - Ground for add Digital
Digital colon difference signal input form field memory
Digital luminance signal intput form field memory
In
In Clock input
Out Digital colon difference signal output for field memory
In
In Digital signal input from A/D
Out Digital luminance signal output for field memory
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (5/6)
