JVC GR-DVA10 Technical Guide

2-21
•
••
•
Camera DSP (IC4301: JCY0120) pin functions (6/6)
Pin No. Label In/Out Description
6 ADDVDDE - Power supply for add Digital (I/O)
9 RE In Read enable
235 HWE In High address write enable
8 LWE In Low address write enable
168 ALE In Address latch enable
230 BUS15
87 BUS14
163 BUS13
231 BUS12
2BUS11
88 BUS10
164 BUS9
89 BUS8
3BUS7
90 BUS6
4BUS5
165 BUS4
233 BUS3
5BUS2
91 BUS1
166 BUS0
234 VSS - Ground for Digital
124 CLR In Clear input
160 VDCPU Out Vertical reference pulse output for CPU
228 HDCPU Out Horizontal reference pulse output for CPU
159 FRP Out Frame detect pulse output
227 OMT Out EIS read-out data enable flag output
85 AFBEND Out CPU interrupt pulse output
161 FLDCPU Out Field discriminate pulse output for CPU
287 BEND Out Block average data interrupt pulse output
229 VSS - Ground for Digital
92 DSTB In Data strobe
104 VPD In Test pin for pull-up
10 CS In Chip select
93 RWSEL In Read write select
288 VDDI - Power supply for Digital (I/O, internal)
157 CLKOSD Out Clock output for OSD
84 HDOSD Out Horizontal reference signal for OSD
226 VDOSD Out Vertical reference signal for OSD
225 BLK1 In Blank signal 1
156 BLK2 In Blank signal 2
81 VC1 In Character signal 1
224 VC2 In Character signal 2
155 VR In Character signal 3R
82 VG In Character signal 3G
285 VB In Character signal 3B
80 VBLK In Blank signal 3
83 ADDVSS - Ground for add Digital
In/Out CPU bus I/O
Table 2-4-1 Camera DSP (IC4301: JCY0120) pin functions (6/6)
