JVC GR-DVL367EG - Section 1; Table of Contents

TABLE OF CONTENTS
DIFFERENT TABLE ........................................................................................................................................................... 1 to 3
4. CHARTS AND DIAGRAMS (4-1 to 4-5)
4.1 JACK SCHEMATIC DIAGRAM ...................................................................................................................................... 4-1
4.2 DSC SCHEMATIC DIAGRAM ....................................................................................................................................... 4-2
4.3 DSC CIRCUIT BOARD ................................................................................................................................................. 4-4
5. PARTS LIST (5-1 to 5-15)
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1
5.2 FINAL ASSEMBLY <M2> .............................................................................................................................................. 5-3
5.3 MONITOR ASSEMBLY <M5> [GR-DVL567EG] ............................................................................................................ 5-6
5.4 ELECTRICAL PARTS LIST ........................................................................................................................................... 5-7
MAIN BOARD ASSEMBLY <01> ...................................................................................................................................... 5-7
DSC BOARD ASSEMBLY <10> ..................................................................................................................................... 5-15
The following table indicate main different points between models GR-DVL167EG-X, GR-DVL365EG-X, GR-DVL365EG-Y,
GR-DVL365EK, GR-DVL367EG-X, GR-DVL367EK and GR-DVL567EG-X.
The following table indicate different parts number between models GR-DVL167EG-X, GR-DVL365EG-X, GR-DVL365EG-Y,
GR-DVL365EK, GR-DVL367EG-X, GR-DVL367EK and GR-DVL567EG-X.
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
!
REF.
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
No.
ITEM
1 PACKING CASE LY32567-001B LY32567-006B LY32567-003A
4 POLY BAG QPA02003506 YQM30061-3 QPA02003506 YQM30061-3 QPA02003506
8 Q.CARD(JUK) — — — LYT0194-001B — LYT0194-001B —
9 WARRANTY CARD BT-54013-2 — BT-54013-2 — BT-54013-2
10 GUARANTY CARD — — — BT-54008-2 — BT-54008-2 —
11 PAMPHLET(EK) — — — LYT0867-001A — LYT0867-001A —
12 SHEET(ATT.) LYT0974-001A — — — — — —
13 SHEET(E.UE) — — LYT0889-010A — — — —
18 CABLE ASSY — PEAC0428-150
19 CORE FILTER — QQR0491-002
20 USB CABLE — QAM0324-001
21 CORE FILTER — QQR0491-002
22 PC CONNECTION CABLE QAM0084-001 — — — — — —
23 CORE FILTER QQR0491-002 — — — — — —
25 CORE FILTER QQR0490-002 QQR0917-002
! 26 POWER CORD QMPL120-190-JR QMPP110-190-JR QMPL120-190-JR QMPP110-190-JR QMPL120-190-JR
27 RM(EDITING)CABLE QAM0214-001 — — — — — —
28 CORE FILTER QQR0491-002 — — — — — —
34 CD ROM ASSY LY32210-022A LY32210-023A
37 MEMORY CARD — QAM0404-002
41 STICKER(EK) — — — LY43496-001A — LY43496-001A —
42 CORE FILTER — QQR0919-002
43 CORE FILTER — *QQR0491-002
MODEL
GR-DVL167EG-X GR-DVL365EG-X GR-DVL365EG-Y GR-DVL365EK GR-DVL367EG-X GR-DVL367EK GR-DVL567EG-X
ITEM
LCD MONITOR 2.5” 3.5”
MEMORY CARD Not Used Provided,8MB(MMC)
DV TERMINAL IN/OUT OUTPUT ONLY IN/OUT
DSC Not Used Used
Notes : Mark is same as left.
Mark — is not used.
Mark * reference model was also changed.
1
