EN75
Controls
1 Monitor Open Button
[PUSH OPEN] ..................................... 墌 pg. 16
2 Diopter Adjustment Control ................. 墌 pg. 10
3 Battery Release Button
[BATTERY RELEASE] .............................. 墌 pg. 9
4 •MENU Wheel [+, –, PUSH] ............... 墌 pg. 24
•LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. 墌 pg. 16
5 Snapshot Button
[SNAPSHOT] ........................... 墌 pg. 18, 19, 49
6 •Power Zoom Lever [T/W] .................. 墌 pg. 20
•Speaker Volume Control [VOL.] ........ 墌 pg. 33
7 Snapshot Mode Button
[MODE] ........................................ 墌 pg. 18, 19
8 OPEN/EJECT Switch ............................. 墌 pg. 12
9 Stop Button [5] ................................... 墌 pg. 33
0 •Rewind Button [
2
] ......................... 墌 pg. 33
•BACKLIGHT Button .......................... 墌 pg. 31
! Play/Pause Button [
4
/6] ...................... 墌 pg. 33
@ •Fast-Forward Button [
3
] ................. 墌 pg. 33
•FOCUS Button .................................. 墌 pg. 23
# Power Switch
[ , , , OFF] ........................... 墌 pg. 15
$ Recording Start/Stop Button.................. 墌 pg. 16
% Lock Button ......................................... 墌 pg. 15
^ VIDEO/DSC Switch [VIDEO, ] ...... 墌 pg. 15
& Video Light Switch
[LIGHT OFF/AUTO/ON] ...................... 墌 pg. 22
Connectors
To connect cables to the following connectors
*
and
(
,
open the LCD monitor.
* PC (DIGITAL PHOTO) Connector ........ 墌 pg. 44
( J Terminal/Edit Connector [JLIP (Joint Level
Interface Protocol)/EDIT] ...................... 墌 pg. 55
• Connect the editing cable when performing
Random Assemble Editing.
• Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
) DC Input Connector .............................. 墌 pg. 9
The connectors
q
to
e
are located beneath a cover.
q Audio/Video Output Connector
[AV] ........................................ 墌 pg. 42, 46, 55
w Digital Video Connector [DV IN/OUT]
(i.link*) .................................... 墌 pg. 44, 45, 47
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
e S-Video Output Connector [S] ... 墌 pg. 42, 46, 55
Indicators
r Tally Lamp ........................................... 墌 pg. 16
t Side LED Indicator ............................... 墌 pg. 26
y Power Lamp ........................................ 墌 pg. 16
Other Parts
u • Remote Sensor .................................. 墌 pg. 50
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
i Viewfinder ........................................... 墌 pg. 10
o Video Light .......................................... 墌 pg. 22
p Stereo Microphone .............................. 墌 pg. 60
Q Shoulder Strap Eyelets .......................... 墌 pg. 10
W Grip Strap ............................................ 墌 pg. 10
E Battery Pack Mount ............................... 墌 pg. 9
R LCD Monitor ................................. 墌 pg. 16, 17
T Speaker ............................................... 墌 pg. 33
Y Stud Hole ............................................ 墌 pg. 10
U Tripod Mounting Socket ....................... 墌 pg. 10
