JVC GR-DVM90

EN99
For Connectors
Video output :1 V ( p-p ) , 75 Ω, analog
Audio output : 300 mV (rms), 1 kΩ, analog, stereo
DV Input/output : 4-pin, IEEE 1394 compliant
Headphone output : ø3.5 mm, stereo
AC Power Adapter/Charger AA-V51U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V , 0.77 A
VTR : DC 6.3 V , 1.8 A
Dimensions (W x H x D) : 68 mm x 45 mm x 110 mm (2-11/16" x 1-13/16" x 4-3/8")
Weight : Approx. 254.5 g (0.57 lbs)
Docking Station CU-V502U
For General
Dimensions (W x H x D) : 55 mm x 36 mm x 107 mm (2-3/16" x 1-7/16" x 4-1/4")
Weight : Approx. 89.9 g (0.2 lbs)
For Connectors
S-Video : Y: 1 V (p-p), 75 Ω, analog output
C: 0.29 V (p-p), 75 Ω, analog output
Video : 1 V (p-p), 75 Ω, analog output
Audio : 300 mV (rms), 1 kΩ, analog output
JLIP (EDIT) : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
PC (DIGITAL STILL) : ø2.5 mm, 3-pole
External microphone input : 506 µV (rms), high impedance unbalanced with ø3.5 mm (stereo)
PRINTER : For an optional video printer equipped with a PRINT DATA
connector
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
