Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
For Connectors
S/AV
S-Video output : Y: 1.0 V (p-p), 75 Ω, analogue output
C: 0.30 V (p-p), 75 Ω, analogue output
Video output : 1.0 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Edit : ø3.5 mm, 2-pole
Headphone output :Stereo
DV
Input/output
(GR-DVP7 only)
: 4-pin, IEEE 1394 compliant
Output
(GR-DVP5 only)
: 4-pin, IEEE 1394 compliant
USB :5-pin
AC Power Adapter/Charger
For General
Power requirement : AC 110 V to 240 Vd, 50 Hz/60 Hz
Power consumption :23W
Output
Charge : DC 7.2 V
G, 1.2 A
VTR : DC 6.3 V
G, 1.8 A
Weight : Approx. 250 g (AA-V100EG)
Approx. 325 g (AA-V100EK)
