5-7
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
******************************
MECHANISM ASSEMBLY <M3>
400 YMA0029C MECHA(A)ASSY
401 LY31543-002E CASSETTE HOUSING ASSY
402 YQ43893-8 MINI SCREW,X3
403 LY31542-001J UPPER BASE ASSY
404 YQ43893 MINI SCREW
405 YDV2096B DRUM ASSY
406 LY42820-001A DAMPER SCREW ASSY,X2
407 LY42820-002A DAMPER SCREW ASSY
408 LY31538-001B REEL DISK ASSY
409 LY31538-002B REEL DISK ASSY
410 YQ44246 SLIT WASHER,X2
411 LY10217-001D REEL COVER ASSY
412 LY42120-001A MINI SCREW
413 LY41945-003A MINI SCREW,X2
414 YQ44246 SLIT WASHER,X2
415 LY42025-001C TENSION ARM ASSY
416 LY31535-001F SLANT POLE ARM ASSY
417 LY42031-001G TU ARM ASSY
418 LY31531-001D SWING ARM ASSY
419 YQ43893 MINI SCREW
420 LY20530-003B SLIDE DECK FINAL ASSY
421 YQ43893 MINI SCREW,X2
422 LY43023-001A MINI SCREW
424 LY31533-001E PAD ARM ASSY
425 YQ44246 SLIT WASHER
428 LY42016-001B TU BRAKE ASSY
429 YQ44246 SLIT WASHER
430 LY41959-001B TENSION CONTROL LEVER ASSY
431 LY31525-001B CENTER GEAR
432 LY31516-001E PINCH ROLLER ARM FINAL ASSY
433 YQ44246 SLIT WASHER
434 LY41956-001C TENSION CONTROL PLATE ASSY
435 LY41962-001B BRAKE CONTROL LEVER ASSY
436 LY20525-002C MOTOR BRACKET ASSY
436A QAR0138-001 LOADING MOTOR
436B LY41940-001A TAPPING SCREW,X2
437 YQ43893 MINI SCREW,X3
438 LY20528-001R GUIDE RAIL ASSY
439 YQ43893 MINI SCREW
440 YQ44246 SLIT WASHER,X2
441 LY31498-001C SLIDE LEVER2 ASSY
442 LY41965-001A LOADING PLATE ASSY
443 YQ44246 SLIT WASHER
444 LY31522-001B EJECT LEVER
445 YQ44246 SLIT WASHER
446 LY41929-001E BASE R ASSY
447 YQ43893 MINI SCREW
448 LY41945-001B MINI SCREW
449 LY41930-001A MODE GEAR
450 QSW0876-003 ROTARY ENCODER
451 YQ43893 MINI SCREW,X2
452 LY31524-001A GEAR COVER ASSY
453 YQ43893 MINI SCREW,X2
454 YQ43893-4 MINI SCREW
455 LY41948-001C MAIN CAM ASSY
456 LY41941-001B SLIDE ARM ASSY
457 LY41951-001B CONNECT GEAR 2
458 LY41954-001B SUB CAM ASSY
459 LY42120-001A MINI SCREW
460 LY41952-001A CONTROL ARM ASSY
461 LY31523-001B REEL GEAR 1
462 LY31508-002A DRUM BASE ASSY
463 QYSPSPU1425M SCREW,X3
464 QAR0142-001 CAPSTAN MOTOR
465 YQ43893 MINI SCREW
466 LY10210-001D MAIN DECK ASSY
476 YQ44246 SLIT WASHER
