5-18
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C7227 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C7228 NCBA1AK-104W CAPACITOR 0.1
µ F,10V
C7229 NBP21DM-475X T CAPACITOR 4.7
µ F,20V
C7230 NBP21VM-155X T CAPACITOR 1.5 µ F,35V
C7231 NBE90JM-106X T CAPACITOR 10 µ F,6.3V
C8001 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8002 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8003 NBZ0015-106X T CAPACITOR 10
µ F,6.3V
C8004 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8005 NCBA1AK-104W CAPACITOR 0.1
µ F,10V
C8006 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8007 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8008 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8009 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8010 NCBA1AK-104W CAPACITOR 0.1
µ F,10V
C8011 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8014 NCBA1AK-104W CAPACITOR 0.1
µ F,10V
C8015 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8016 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8017 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8018 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8019 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8020 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8021 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8022 NCB30JK-105X CAPACITOR 1 µ F,6.3V
C8023 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C8024 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C8025 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C8026 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C8301 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8305 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8306 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8307 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8310 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8311 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8501 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C8502 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8503 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8504 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
C8505 NCBA1AK-104W CAPACITOR 0.1 µ F,10V
L1002 NQR0006-001X FERRITE BEAD
L1101 NQL402M-100X COIL 10 µ H
L1401 NQR0006-001X FERRITE BEAD
L2101 NQL402M-100X COIL 10 µ H
L2401 NQL402M-100X COIL 10 µ H
L2402 NQL402M-100X COIL 10 µ H
L2601 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
L2602 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
L2603 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
L2701 NQR0129-002X FERRITE BEAD
L3001 NQR0129-002X FERRITE BEAD
L3002 NQR0129-002X FERRITE BEAD
L3004 NQR0006-001X FERRITE BEAD
L3005 NQR0006-001X FERRITE BEAD
L3007 NQL085J-2R2X COIL 2.2 µ H
L3008 NQL085J-120X COIL 12 µ H
L3010 NQR0383-003X COIL
L3011 NQR0383-003X COIL
L3012 NQR0006-001X FERRITE BEAD
L3013 NQR0129-002X FERRITE BEAD
L3501 NQR0129-002X FERRITE BEAD
L3502 NQL402M-100X COIL 10 µ H
L3503 NQR0006-001X FERRITE BEAD
L3504 NQR0006-001X FERRITE BEAD
L3505 NQR0006-001X FERRITE BEAD
L3701 NQL38DK-100X COIL 10 µ H
L3731 NQL085J-6R8X COIL 6.8 µ H
L3732 NQL085J-6R8X COIL 6.8 µ H
L3801 NQR0129-002X FERRITE BEAD
L3802 NQR0129-002X FERRITE BEAD
L3803 NQR0006-001X FERRITE BEAD
L3804 NQL38DK-100X COIL 10
µ H
L3901 NQL38DK-100X COIL 10
µ H
L4201 NQL38DK-100X COIL 10 µ H
L4301 NQR0129-002X FERRITE BEAD
L4302 NQR0129-002X FERRITE BEAD
L4303 NQR0129-002X FERRITE BEAD
L4304 NQR0129-002X FERRITE BEAD
L5001 NQR0129-002X FERRITE BEAD
L5002 NQL38DK-100X COIL 10 µ H
L5003 NQL38DK-100X COIL 10 µ H
L5004 NQL38DK-100X COIL 10 µ H
L5005 NQR0129-002X FERRITE BEAD
L5006 NQL38DK-100X COIL 10 µ H
L5007 NQR0129-002X FERRITE BEAD
L6001 NQL402M-100X COIL 10 µ H
L6101 NQL68EM-100X COIL 10 µ H
L6102 NQL68EM-100X COIL 10 µ H
L6103 NQLZ010-390X COIL 39 µ H
L6104 NQL68EM-330X COIL 33 µ H
L6105 NQL68EM-330X COIL 33 µ H
L6106 NQL68EM-470X COIL 47 µ H
L6107 NQL68EM-330X COIL 33 µ H
L6108 NQL144K-220X COIL 22 µ H
L6109 NQLZ011-221X COIL 220 µ H
L7102 NQL38DK-220X COIL 22 µ H
L7103 NQL38DK-220X COIL 22 µ H
L7104 NQL38DK-220X COIL 22 µ H
L7201 NQL38DK-220X COIL 22 µ H
L7202 NQL38DK-220X COIL 22 µ H
L7203 NQL38DK-220X COIL 22 µ H
L7204 NQL38DK-220X COIL 22 µ H
L7205 NQL38DK-100X COIL 10 µ H
L8001 NQR0129-002X FERRITE BEAD
L8002 NQR0129-002X FERRITE BEAD
L8003 NQR0006-001X FERRITE BEAD
L8004 NQR0129-002X FERRITE BEAD
L8005 NQR0129-002X FERRITE BEAD
L8006 NQR0006-001X FERRITE BEAD
L8301 NQR0129-002X FERRITE BEAD
L8501 NQR0129-002X FERRITE BEAD
X1001 NAX0474-001X C OSCILLATOR
X1002 NAX0546-001X CRYSTAL RESONATOR
X1401 NAX0175-001X CRYSTAL RESONATOR
X3002 NAX0480-001X CRYSTAL RESONATOR
X4301 NAX0319-001X CXO
X8301 NAX0522-001X RESONATOR
S1001 NSW0182-001X PUSH SWITCH,MONITOR SW
TB1 LY32205-001A BATTERY TERMINAL UNIT
J101 QNZ0518-002 D CONNECTOR
CN101 QGF0517F1-08X FPC CONNECTOR
CN102 QGF0520F1-06X FFC/FPC CONNECTOR
CN103 QGF0520F1-06X FFC/FPC CONNECTOR
CN104 QGF0517F2-11X FPC CONNECTOR
CN105 QGF0517F2-18X FPC CONNECTOR
CN106 QGF0517F2-16X FPC CONNECTOR
