36 EN
1
3
2
+
–
+
–
Installing The Batteries
The remote control uses two “AAA (R03)” size batteries.
See “General Battery Precautions” (墌 pg. 52).
1
Open the battery compartment cover as illustrated.
2
Insert two “AAA (R03)” size batteries in the correct
direction.
3
Replace the battery compartment cover.
Tab
USING THE REMOTE CONTROL UNIT
(cont.)
When using the remote control, be sure to point it
at the remote sensor. The illustration shows the
approximate transmitted beam effective area for
indoor use.
The transmitted beam may not be effective or may
cause incorrect operation outdoors or when the
remote sensor is directly exposed to sunlight or
powerful lighting.
Transmitted beam
effective area
Remote sensor
To Next Page
