Controls
1 Video Light Switch [LIGHT OFF/AUTO/ON]
(GR-SXM86ED/SXM85ED/SXM76ED/
SX56ED only) ...................................... 墌 pg. 17
2 Stop Button [STOP] .............................. 墌 pg. 30
3 • Retake Rewind Button [RETAKE R] ..... 墌 pg. 17
•Quick Review Button [ R] ............ 墌 pg. 17
•Rewind Button [R] ............................. 墌 pg. 30
4 Play/Pause Button ................................ 墌 pg. 30
5 • Retake Forward Button [RETAKE F] .... 墌 pg. 17
•Fast-Forward Button [F] ..................... 墌 pg. 30
6 •Fade/Wipe Button [FADE/WIPE] ........ 墌 pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] .............................. 墌 pg. 31
7 Program AE Button [P. AE] .................... 墌 pg. 20
8 Digital Effect Button [DIGIFECT] .......... 墌 pg. 21
9 NIGHT-SCOPE Button ......................... 墌 pg. 18
0 REFRESH Button .................................... 墌 pg. 6
! EJECT Switch ....................................... 墌 pg. 13
@ Close Button ........................................ 墌 pg. 13
# •MENU Wheel [–, +] .......................... 墌 pg. 22
•BRIGHT Wheel [–, +]
(models equipped with
LCD monitor only) ...................... 墌 pg. 14, 30
•TRACKING Wheel [–, +] ................... 墌 pg. 31
$ Snapshot Button [SNAPSHOT] ............. 墌 pg. 18
% •Power Zoom Lever [T/W] .................. 墌 pg. 16
•Speaker Volume Control [VOL.]
(models equipped with
LCD monitor only) ............................ 墌 pg. 30
^ • Picture Stabiliser Button
[P. STABILIZER] ................................. 墌 pg. 16
•Time Base Corrector Button [TBC] ..... 墌 pg. 31
& Power Switch
[ , OFF, , ] ...................... 墌 pg. 14, 30
* Recording Start/Stop Button .................. 墌 pg. 14
( Battery Release Switch
[BATTERY RELEASE] .............................. 墌 pg. 6
) Dioptre Adjustment Control ................... 墌 pg. 8
Connectors
The connectors q to t are located beneath the
cover.
q S-Video Output Connector [S]
(GR-SXM86ED/SXM85ED/SXM76ED/
SX56ED only) ...................................... 墌 pg. 32
w Audio Output Connector [A] ................ 墌 pg. 32
e Video Output Connector [V] ................ 墌 pg. 32
r J Terminal/Edit Connector
[JLIP (Joint Level Interface Protocol)/EDIT]
•Connect the editing cable when performing
Random Assemble Editing (墌 pg. 40 – 43).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
t DC IN Connector ............................... 墌 pg. 6, 7
Indicators
y CHARGE Lamp ...................................... 墌 pg. 6
u •Power Lamp ..................................... 墌 pg. 14
•REFRESH Lamp ................................... 墌 pg. 6
Other Parts
i LCD Monitor (models equipped
with LCD monitor only) ................. 墌 pg. 14, 15
o Shoulder Strap Eyelets ............................ 墌 pg. 8
p Eyepiece
Q Battery Pack Mount ............................... 墌 pg. 6
W Viewfinder ............................................. 墌 pg. 8
E Speaker (models equipped
with LCD monitor only) ....................... 墌 pg. 30
R • Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. 墌 pg. 36
T Grip Strap .............................................. 墌 pg. 8
Y Microphone ......................................... 墌 pg. 39
U Video Light
(GR-SXM86ED/SXM85ED/SXM76ED/
SX56ED only) ...................................... 墌 pg. 17
I Tripod Mounting Socket ......................... 墌 pg. 8
